Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1630 x 2240 x 1270 mm | |
|---|---|---|
| Floor to top of platform slat base | 152 mm | |
| Recommended mattress thickness | 305 mm | |
| Headboard panel thickness | 203 mm | |
| Side rail height above floor | 356 mm | |
| Footboard height above floor | 356 mm | |
| Support foot height | 51 mm | |
| Slat width | 70 mm | |
| Slat spacing gap | 76 mm | |
| Center support beam length | 2030 mm | |
| Underbed clearance height | 51 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 455 kg | |
|---|---|---|
| Product net weight | 82 kg | |
| Slat static load per unit | 45 kg | |
| Recommended user count | 2 adults | |
| Noise rating under normal use | 25 dB | |
| Edge load capacity | 136 kg | |
| Recommended warranty period | 1 year | |
| Fabric abrasion resistance | 15000 double rubs | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery fabric | 100% polyester light gray looped boucle fabric | |
|---|---|---|
| Headboard padding | 38 kg/m³ high-density polyurethane foam | |
| Side and foot rail padding | 32 kg/m³ high-density polyurethane foam | |
| Internal structural frame | 18 mm thick pine plywood and solid pine lumber | |
| Support slats | 12 mm thick solid bentwood slats | |
| Center support beam | 25 mm thick engineered wood beam with metal reinforcement brackets | |
| Support feet | 30 mm diameter black matte polypropylene feet | |
| Hardware fasteners | Zinc-plated steel screws and barrel bolts | |
| Fabric stain resistance | Stain-repellent treated polyester fabric | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Solid wood slat platform, no box spring required | |
|---|---|---|
| Safety edge design | Fully rounded soft upholstered corners on all frame components | |
| Anti-slip mattress retention | Embedded non-slip fabric strips on slat surface | |
| Noise dampening system | EVA foam buffers between slats and frame rails | |
| Assembly design | Pre-drilled labeled components with cam-lock fasteners | |
| Weight distribution | 14 slats plus 1 center support beam | |
| Floor protection | Non-marking felt pads on base of each support foot | |
| Headboard attachment | Bolt-on fixed connection to side rails | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential primary bedroom | Suitable for queen-size bed layout in modern minimalist, Scandinavian, or soft contemporary interiors | |
|---|---|---|
| Small urban apartment bedroom | Low-profile design creates open visual feel without overwhelming compact spaces | |
| Guest bedroom suite | Soft neutral gray finish and rounded edges coordinate with most guest room decor palettes | |
| Households with children | Rounded soft upholstered edges eliminate sharp corner injury risks for active kids | |
| Recommended mattress type | Memory foam, latex, or hybrid mattresses 305 mm thick for best visual proportion | |
| Recommended placement | Positioned against a wall with the split asymmetrical headboard centered for balanced visual appeal |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability by smouldering cigarette, fire safety requirement |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural performance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emissions | |
| GB/T 19851.1-2005 | Safety requirements for upholstered furniture, applicable to structural stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural performance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emissions; 3. GB/T 19851.1-2005: Safety requirements for upholstered furniture, applicable to structural stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
