Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2000 x 2200 x 400 mm | |
|---|---|---|
| mattress recess inner dimensions | 1800 x 2000 x 150 mm | |
| mattress support surface height | 400 mm | |
| perimeter frame width | 100 mm | |
| frame upholstery padding thickness | 80 mm | |
| segmented seam spacing on frame | 300 mm | |
| under-bed floor clearance | 0 mm | |
| head end bolster cushion thickness | 120 mm | |
| recommended mattress thickness | 300 mm | |
| corner radius on frame edges | 150 mm | |
| slat support count | 28 | |
| slat spacing | 70 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| net product weight | 70 kg | |
|---|---|---|
| static total load capacity | 363 kg | |
| perimeter edge static load resistance | 100 kg | |
| recommended user count | 2 | |
| foam padding compression recovery rate | 90% | |
| fabric abrasion resistance (Martindale) | 30000 cycles | |
| structural connector static shear strength | 800 kg | |
| frame structural warranty period | 1 year | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer upholstery | Cream textured boucle (teddy fleece) fabric with 1.5mm pile | |
|---|---|---|
| internal support frame | 18mm thick engineered plywood frame | |
| frame padding | 30kg/m³ density high-resilience polyurethane foam | |
| slatted support base | 12mm thick pine wood slats mounted on steel cross rails | |
| seam construction | Double-stitched seams with 8mm stitch pitch | |
| support leg structure | Full perimeter floor-contact fabric-wrapped base, no exposed legs | |
| hardware fittings | Zinc-plated steel KD connector bolts and barrel nuts | |
| head end bolster fill | 25mm polyester fiber wrap over foam core | |
| underside base covering | Black non-woven fabric dust cover | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| mattress support system | Fixed slat base with no moving parts, eliminates need for box spring | |
|---|---|---|
| recessed frame retention | Raised perimeter frame holds mattress in place to prevent sliding | |
| assembly structure | Knock-down flat pack assembly with hex key hardware, no specialized tools | |
| floor contact stability | Full perimeter base distributes weight evenly to eliminate wobble | |
| edge sitting support | Reinforced perimeter frame supports seated use without edge sag | |
| cleaning functionality | Removable spot-cleanable fabric surface for stain maintenance | |
| noise damping performance | Foam-padded joints and wood slats reduce squeaking during use | |
| orientation functionality | Fixed head-end design with integrated bolster support for pillow placement | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| residential master bedroom | Low-profile minimalist design suitable for contemporary, wabi-sabi or cream style interiors | |
|---|---|---|
| small apartment bedroom | Compact floor-standing design saves vertical space without raised legs or bulky headboard | |
| boutique hotel guest room | Soft neutral upholstery provides premium residential feel for accommodation settings | |
| secondary bedroom / guest room | Wrap-around padded edges offer safe, comfortable design for occasional guest use | |
| young adult bedroom | Casual cozy boucle texture fits casual modern home decor for younger users | |
| minimalist studio space | Low silhouette avoids visual clutter in open-plan living and sleeping spaces |
EU Market Access Requirements* EN Standards
| EN 1725:2010 | Furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating, test methods for stability applicable to bed edge use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame structural integrity | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, mattresses and bed bases |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame structural integrity; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, mattresses and bed bases; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
