Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (Queen size reference) | 2170 x 1690 x 1020 mm | |
|---|---|---|
| Mattress fit size | 1600 x 2000 mm | |
| Headboard panel width (each split cushion) | 820 mm | |
| Floor to slat support height | 280 mm | |
| Under-bed clearance (floor to rail bottom) | 200 mm | |
| Headboard cushion thickness | 120 mm | |
| Side rail width (extended ledge) | 45 mm | |
| Leg diameter/width | 30 mm | |
| Recommended mattress thickness | 300 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 590 kg | |
|---|---|---|
| Slat spacing | 76 mm | |
| Number of support slats | 28 | |
| Center support leg count | 3 | |
| Assembly time | 60 minutes | |
| Product net weight | 62 kg | |
| Upholstery abrasion resistance | 50000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Light taupe faux leather or woven polyester fabric | |
|---|---|---|
| Headboard padding | 35 kg/m³ high-density polyurethane foam | |
| Internal frame | 18 mm thick plywood and engineered hardwood | |
| Support slats | 12 mm thick bentwood plywood slats | |
| Support legs | Chrome-plated square steel tube, 1.5 mm wall thickness | |
| Side rails | Upholstered plywood frame with matching taupe covering | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts | |
| Noise reduction pads | EVA rubber pads at slat and leg contact points | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Support system | Wood slat platform with center support beam, no box spring required | |
|---|---|---|
| Assembly method | Knock-down flat pack, included hex key and hardware | |
| Headboard design | Two independent split padded cushions, fixed height | |
| Extended side rail ledge | Narrow overhanging edge along perimeter, no storage function | |
| Under-bed access | 200 mm clearance for robot vacuum access and light cleaning | |
| Mattress retention | Raised slat frame lip to prevent mattress sliding | |
| Leg finish | Polished chrome plated surface with non-slip floor glides | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Modern minimalist design fits contemporary neutral-tone bedroom interiors | |
|---|---|---|
| Apartment and urban living spaces | Low-profile silhouette fits rooms with lower ceiling heights | |
| Hotel guest room furnishing | Neutral taupe finish and durable construction suitable for hospitality use | |
| Pairing recommendation | Works with low-profile modern nightstands in matching metal or light wood finish | |
| User group | Adult sleepers preferring soft upholstered headboard support without bulky footboard | |
| Floor compatibility | Suitable for hard wood, tile and low-pile carpeted floors with included glides |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses, safety and strength requirements | |
|---|---|---|
| EN 1022:2005 | Domestic furniture - Seating, applicable to headboard structural stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame safety | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, applicable to mattress support performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame safety; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, applicable to mattress support performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
