Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x L x H) | 1880 x 2230 x 1270 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1270 mm | |
| Footboard height from floor | 420 mm | |
| Platform support height from floor | 300 mm | |
| Under-bed clearance from floor | 200 mm | |
| Side rail thickness | 80 mm | |
| Headboard upholstery padding thickness | 80 mm | |
| Footboard upholstery padding thickness | 60 mm | |
| Slat width | 70 mm | |
| Slat spacing | 75 mm | |
| Center support leg count | 3 |
Net weight / load capacity / users / durability
| Total static load capacity (mattress + sleepers) | 500 kg | |
|---|---|---|
| Product net weight | 75 kg | |
| Recommended mattress thickness | 300 mm | |
| Recommended number of users | 2 | |
| Upholstery fabric abrasion resistance | 30000 double rubs | |
| Foam padding density | 32 kg/m³ | |
| Foam rebound rate | 60% | |
| Limited warranty period | 1 year | |
| Color option count | 4 | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Tight-weave light neutral polyester-linen blend fabric | |
|---|---|---|
| Headboard/footboard/rail padding | High-density polyurethane foam padding | |
| Decorative edge trim | Dark contrast fabric piping along all upholstered panel edges | |
| Internal bed frame | Solid pine and engineered plywood structural frame | |
| Mattress support slats | 15mm thick birch plywood slats | |
| Center support structure | Powder-coated steel support beam with adjustable metal legs | |
| Frame hardware | Zinc-plated steel connector bolts and barrel nuts | |
| Footboard upholstery | Matching light neutral vertical channel-tufted fabric, same as headboard | |
| Side rail upholstery | Matching light neutral padded fabric covering full rail surface | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Fixed plywood slat platform eliminates need for separate box spring | |
|---|---|---|
| Assembly design | Knock-down flat-pack assembly with bolted rail-to-headboard/footboard connections | |
| Cleaning access | 200mm under-bed clearance allows robot vacuum and manual cleaning access | |
| Tufting construction | Fixed vertical channel tufting creates defined padded panels on headboard and footboard | |
| Center support adjustment | Adjustable metal center legs allow fine height tuning for level slat surface | |
| Mattress retention | Recessed platform lip prevents mattress sliding during regular use | |
| Care requirement | Spot clean only with mild upholstery cleaner, no machine-washable covers | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Largest carton dimensions (W x D x H) | 200 x 50 x 220 mm | |
|---|---|---|
| Slat pack carton dimensions | 900 x 280 x 60 mm | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential application | Master or guest bedrooms in modern, light luxury residential interiors | |
|---|---|---|
| Compatible mattress types | Memory foam, latex, hybrid, and innerspring mattresses 300 mm thick | |
| Matching furnishing recommendation | Pair with two 550mm tall two-drawer white nightstands and table lamps | |
| Recommended room size | Minimum 3000 x 3600 mm bedroom space for comfortable access around bed | |
| User profile | Adult residential users seeking soft, tailored upholstered bed design without underbed storage | |
| Interior style compatibility | Transitional, modern glam, and contemporary bedroom design schemes |
EU Market Access Requirements* EN Standards
| EN 1725:2012 | Domestic furniture – Beds and mattresses – Safety requirements and test methods, applicable to structural stability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame safety and dimensional accuracy | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission from wood components | |
| GB/T 19821-2005 | Upholstered furniture general technical requirements, applicable to padding and upholstery performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame safety and dimensional accuracy; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission from wood components; 3. GB/T 19821-2005: Upholstered furniture general technical requirements, applicable to padding and upholstery performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
