Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (king size) | 1930 x 2200 x 1330 mm | |
|---|---|---|
| Recommended mattress size | 1800 x 2000 mm | |
| Headboard total height | 1330 mm | |
| Headboard upholstered padding thickness | 120 mm | |
| Bed frame side rail height | 350 mm | |
| Floor clearance under bed frame | 150 mm | |
| Side rail thickness | 30 mm | |
| Recommended mattress thickness | 406 mm | |
| Wing side protrusion from headboard | 80 mm | |
| Vertical center accent strip width | 40 mm | |
| Mattress recess depth | 50 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Maximum static load capacity | 454 kg | |
|---|---|---|
| Recommended user count | 2 adults | |
| Product net weight | 75 kg | |
| Upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Slat static load rating per slat | 60 kg | |
| Noise reduction rating | 25 dB | |
| Limited warranty period | 365 days | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard and bed base upholstery | Woven performance fabric (technology fabric) with soft matte finish | |
|---|---|---|
| Internal bed frame | 15mm thick plywood and mixed hardwood structural frame | |
| Support slats | 25mm thick LVL construction-grade wood slats with EVA silent padding | |
| Support legs | 20mm diameter tapered matte black powder-coated steel legs | |
| Center support beam | 30mm thick engineered wood beam with 3 additional support legs | |
| Hardware components | Zinc-plated steel bolts, barrel nuts, and Allen key assembly hardware | |
| Headboard padding | 35kg/m3 high-density polyurethane foam with 10mm soft polyester fiber wrap | |
| Side rail upholstery padding | 20mm thick 28kg/m3 polyurethane foam | |
| Vertical accent trim | High-gloss white PVC trim with black metal accent band | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Wood slat platform with center support beam, no box spring required | |
|---|---|---|
| Mattress retention feature | Recessed platform edge with 50mm lip to prevent mattress sliding | |
| Assembly design | Knock-down flat-pack construction with included hardware and instructions | |
| Assembly requirement | Two-person assembly with standard household tools | |
| Seam construction | Reinforced stitched seams with 8 stitches per inch seam pitch | |
| Headboard mounting | Fixed bolted connection to side rails with adjustable alignment slots | |
| Floor protection | Non-marking plastic foot caps on all metal legs to prevent floor scratching | |
| Cleaning compatibility | Spot clean only with mild upholstery cleaner and dry cloth | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, sized for king size mattress configuration | |
|---|---|---|
| Secondary application space | Urban apartment guest bedrooms, low-profile design suits smaller ceiling heights | |
| Target user group | Adult users seeking modern light luxury style upholstered bedroom furniture | |
| Recommended pairing | Matching two-drawer upholstered nightstands placed on both sides of the bed | |
| Recommended room size | Minimum 12 sqm bedroom area to allow 600mm clearance on both sides and foot of bed | |
| Style compatibility | Pairs with contemporary, light luxury, and minimalist interior design schemes |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating and beds - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and structural components | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to panel components | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture beds, applicable to overall product performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and structural components; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to panel components; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture beds, applicable to overall product performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
