| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall outer dimensions | 1680 x 2240 x 1320 mm | |
|---|---|---|
| Headboard dimensions | 1680 x 150 x 1320 mm | |
| Side rail height from floor | 300 mm | |
| Underbed clearance | 150 mm | |
| Mattress support platform dimensions | 1530 x 2030 mm | |
| Side rail panel thickness | 100 mm | |
| Slat spacing | 75 mm | |
| Center support beam length | 2030 mm | |
| Leg width at floor contact | 120 mm | |
| Quilted grid square size | 120 x 120 mm | |
| Headboard padding thickness | 80 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 408 kg | |
|---|---|---|
| Recommended mattress thickness | 380 mm | |
| Net product weight | 57 kg | |
| Slat static load rating | 30 kg per slat | |
| Seam stitch durability | 12000 double rubs | |
| Recommended user count | 2 adults | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Exterior upholstery | Brown matte woven polyester fabric | |
|---|---|---|
| Headboard padding | 40 kg/m3 high-resilience polyurethane foam | |
| Side rail padding | 30 kg/m3 polyurethane foam | |
| Internal frame | 18 mm thick plywood and engineered wood | |
| Support slats | 12 mm thick solid pine wood slats | |
| Support legs | 3 mm thick powder-coated black steel | |
| Center support beam | 25 mm thick engineered wood beam | |
| Fastening hardware | Zinc-plated steel bolts and barrel nuts | |
| Anti-slip slat pads | EVA foam padding under slats | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Fixed wood slat platform with center beam | |
|---|---|---|
| Headboard function | Padded vertical backrest for seated reading in bed | |
| Leg design | Recessed angled black metal legs | |
| Slat attachment | Secured slats with anti-slip pads | |
| Assembly requirement | Knock-down assembly with included hardware | |
| Underbed space | Open 150 mm clearance under frame | |
| Compatibility | Compatible with standard queen size mattresses | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Primary sleeping furniture for modern minimalist or contemporary interior schemes | |
|---|---|---|
| Guest bedroom | Durable low-profile bed for secondary residential sleeping spaces | |
| Urban apartment bedroom | Compact low-profile design fits smaller urban residential floor plans | |
| Boutique hotel guest room | Soft upholstered finish creates comfortable upscale guest room atmosphere | |
| Matching setup | Pairs with low-profile bedroom case goods in dark wood or matte black finishes | |
| Recommended mattress pairing | Pair with 380 mm thick mattress for balanced visual proportion |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture – Beds and mattresses – Safety requirements and test methods | |
|---|---|---|
| EN 12520:2015 | Furniture – Strength, durability and safety – Requirements for domestic seating, applicable to headboard back support |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural performance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, required for indoor air quality | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture mattresses, applicable for support interface |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural performance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, required for indoor air quality; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture mattresses, applicable for support interface; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
