Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Side Rail Thickness | 40 mm | |
|---|---|---|
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Bed structure net weight | 68 kg | |
|---|---|---|
| Recommended maximum user load | 350 kg total static load | |
| Mattress platform distributed load | 250 kg | |
| Sleeping capacity | 2 adults | |
| Slat support spacing | 65 mm | |
| Slat section | 55 x 18 mm | |
| Metal leg tube diameter | 25 mm | |
| Leg assembly static rating | 120 kg per leg | Engineering selection value for four-point support with uneven-loading margin. | |
| Recommended mattress thickness | 220 mm | |
| Warranty target | 36 months |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Headboard upholstery | Cognac brown soft-face upholstery over padded panels | |
|---|---|---|
| Headboard padding | High-resilience polyurethane foam, 40 mm front padding | |
| Headboard internal board | 18 mm engineered wood board | |
| Side and foot rails | Brown upholstered engineered-wood frame with 30 mm visible padding | |
| Bed base support | Bentwood or plywood slat system, 18 mm thick | |
| Support legs | Black powder-coated steel tube, 25 mm diameter | |
| Leg mounting plates | Steel mounting plate, 2.5 mm thick target | |
| Decorative wing trim | Dark narrow edge insert along both headboard wings | |
| Panel seams | Stitched or molded vertical dividing seams on headboard | |
| Corner construction | Rounded upholstered front corners on side and foot rails | |
| Floor contact pads | Black non-marking foot pads under steel legs | |
| Display bedding | Woven pillows, polyester-cotton sheet and check bed runner |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Sleeping configuration | Fixed king-size double bed platform for a 1800 x 2000 mm mattress | |
|---|---|---|
| Headboard support | Winged padded headboard provides seated back support while reading or using a device against the wall | |
| Mattress retention | Upholstered side and foot rails surround the mattress to limit lateral movement | |
| Under-bed access | 120 mm floor clearance allows robotic vacuum passage and limited under-bed cleaning | |
| Leg installation | Four screw-on black steel legs attach to the upholstered rails for knockdown transport | |
| Bed placement | Headboard is designed for wall placement with side access around the foot and both rails | |
| Noise control target | Slats and mounting plates should use 1 mm anti-slip gaskets at contact points | |
| Assembly method | Two-person knockdown assembly using bolts, lock washers and pre-installed threaded inserts | |
| Floor protection | Rigid steel legs terminate in separate non-marking pads suitable for tile or wood flooring | |
| Bedding compatibility | Accommodates fitted sheets for a 220 mm thick mattress and standard king-size duvet | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary bedroom | Suits a 12 square meter or larger bedroom where a 1800 mm king bed is used by two adults | |
|---|---|---|
| Hotel or serviced apartment | Appropriate for upscale rooms requiring a soft cognac headboard and durable fixed platform construction | |
| Model home or showroom | Works as a visual anchor because the padded headboard and layered bedding create a warm modern display | |
| Reading in bed | Suitable for upright reading with pillows against the fixed 1250 mm padded headboard | |
| Hard-floor installation | Suitable for marble, tile, wood or laminate floors when fitted with non-marking pads under steel legs | |
| Storage-limited layout | Best selected where under-bed storage bins are not required, because the rail design prioritizes a low profile over drawers |
EU Market Access Requirements* EN Standards
| Furniture strength and durability | EN 1725:1998 | |
|---|---|---|
| Upholstered furniture burning behavior | BS EN 1021:2014 and BS EN 1021:2014 | |
| Wood-based panels formaldehyde | EN 13986:2004+A1:2015 |
Standards applicable to China-market projects
| Dimensional coordination | GB/T 3324wooden furniture general technical requirements | |
|---|---|---|
| Formaldehyde control | GB 18580 | |
| Upholstered furniture safety | GB/T 33247 |
This product must meet the following technical requirements: 1. Dimensional coordination: GB/T 3324wooden furniture general technical requirements; 2. Formaldehyde control: GB 18580; 3. Upholstered furniture safety: GB/T 33247; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
