Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Side Rail Thickness | 40 mm | |
|---|---|---|
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Bed static load capacity | 350 kg | |
|---|---|---|
| Recommended occupant count | 2 adults | |
| Bed net weight | 75 kg | |
| Hardware cycle rating | 50000 drawer cycles | |
| Deck support point spacing | 350 mm | |
| Warranty target | 5 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Headboard upholstery | Woven fabric or leather-look surface over padded panels | |
|---|---|---|
| Headboard padding | 40 mm polyurethane foam over a hard backing panel | |
| Headboard internal panel | 18 mm engineered wood board | |
| Side and foot rails | Upholstered engineered-wood frame with stitched panel seams | |
| Support deck | Engineered wood slats or board panels on perimeter rails | |
| Bed legs | Black powder-coated steel or coated metal legs, 30 mm section | |
| Nightstand carcass | 18 mm wood-based board with matching upholstered or laminated fronts | |
| Nightstand drawer pulls | Dark rectangular metal handles, 80 mm wide | |
| Drawer runners | Side-mounted ball-bearing or roller slides, 350 mm nominal length | |
| Decorative inset strips | Dark gray accent strips embedded in the headboard | |
| Stitching detail | Vertical and horizontal panel seam lines with 80 to 240 mm visual spacing | |
| Feet pads | Dark polymer or metal foot pads with floor-contact base |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Mattress retention | Upholstered side and end rails contain a 1800 x 2000 mm mattress with 10 mm side clearance | |
|---|---|---|
| Headboard support | Padded segmented headboard provides seated back support for reading and pillow protection | |
| Bed base access | 80 mm under-bed clearance allows floor cleaning but not large storage boxes | |
| Nightstand storage | Each matching cabinet provides two stacked drawers for bedside and personal storage | |
| Drawer operation | 350 mm travel slides allow full access to drawer contents with a single centered handle | |
| Bedside surface use | 500 mm high nightstand top supports lamps, drinks, phones and alarm devices | |
| Assembly method | Bolt-on headboard, side rails, foot rail, support deck and legs connect with knockdown hardware | |
| Floor protection | Small feet raise the upholstered base and distribute load away from floor finish | |
| Room layout pairing | Two nightstands can be placed symmetrically on both sides of the 1900 mm wide bed | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Master bedroom | 1900 mm wide double bed suits a main bedroom with two adult users and matching bedside storage | |
|---|---|---|
| Hotel guest room | Padded headboard and coordinated nightstands provide a durable room set for mid-scale hotels | |
| Apartment furnishing | Low-profile design fits serviced apartments and rental homes with restrained modern styling | |
| Showroom display | Upholstered headboard grid, contrasting accents and matching cabinets form a coordinated bedroom display | |
| Small-to-medium bedroom clearance | 2200 mm total length requires 600 mm circulation space at the bed foot for comfortable passage |
EU Market Access Requirements* EN Standards
| Formaldehyde emission recommendation | EN 13986 E1 class for wood-based panels used in bed and cabinet structure | |
|---|---|---|
| Furniture safety recommendation | EN 1725 for residential bed safety, strength and durability requirements | |
| Storage cabinet safety recommendation | EN 14749 for domestic nightstand storage units |
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB/T 39600 E1 limit for engineered wood components | |
|---|---|---|
| Furniture structural safety recommendation | GB/T 3324 for wooden furniture dimensions and structural inspection | |
| Upholstered furniture labeling recommendation | GB/T 16799 for furniture leather if leather upholstery is supplied | |
| Fabric furniture performance recommendation | GB/T 21295 for upholstered furniture physical and chemical properties |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB/T 39600 E1 limit for engineered wood components; 2. Furniture structural safety recommendation: GB/T 3324 for wooden furniture dimensions and structural inspection; 3. Upholstered furniture labeling recommendation: GB/T 16799 for furniture leather if leather upholstery is supplied; 4. Fabric furniture performance recommendation: GB/T 21295 for upholstered furniture physical and chemical properties; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
