Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1920 x 2230 x 1100 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard total height | 1100 mm | |
| Headboard width | 1920 mm | |
| Platform base height | 350 mm | |
| Underbed clearance | 150 mm | |
| Slat thickness | 25 mm | |
| Slat spacing | 70 mm | |
| Brass accent strip size | 1050 x 40 mm | |
| Support leg diameter | 20 mm | |
| Side rail thickness | 30 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 350 kg | |
|---|---|---|
| Product net weight | 70 kg | |
| Number of support slats | 16 | |
| Center support leg count | 3 | |
| Upholstery abrasion resistance | 30000 double rubs | |
| Recommended maximum mattress thickness | 300 mm | |
| Frame static load test weight | 600 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery | Taupe woven polyester fabric | |
|---|---|---|
| Headboard padding | 30mm high-density polyurethane foam | |
| Internal frame | 1.2mm thick square steel tube frame | |
| Mattress support slats | Solid kiln-dried pine wood slats | |
| Support legs | Polished chrome plated solid steel | |
| Headboard decorative accents | Brushed brass finished stainless steel strips | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts | |
| Side rail structure | Engineered wood panel core wrapped in foam and fabric | |
| Seam stitching | High-tenacity polyester thread | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Slatted support system | No box spring required, slats provide direct mattress ventilation | |
|---|---|---|
| Center support structure | Three additional steel center legs reduce slat deflection | |
| Floor protection design | Non-marking plastic glides on all leg bases | |
| Flat-pack assembly | All pre-drilled components and included hex key hardware | |
| Underbed storage access | 150mm clearance allows slim underbed storage bins | |
| Fixed headboard position | Padded headboard aligned flush with wall | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential use | Master bedrooms in contemporary and mid-century modern homes | |
|---|---|---|
| Target users | Adults seeking low-profile, quiet support bed frame | |
| Hotel guest room application | Boutique hotel and short-term rental guest rooms | |
| Recommended matching furniture | Low-profile dressers and brass-accent nightstands | |
| Flooring compatibility | Hardwood, tile, vinyl and low-pile carpeted floors | |
| Mattress pairing recommendation | 300 mm thick memory foam or hybrid mattresses |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture – Beds and mattresses, safety and strength test standard | |
|---|---|---|
| EN 1022:2018 | Domestic furniture – Seating stability, applicable for bed frame stability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wooden slat components | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, for formaldehyde emission verification | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture mattresses, applicable for fit verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wooden slat components; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, for formaldehyde emission verification; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture mattresses, applicable for fit verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
