Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 2200 x 950 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total bed net weight | 85 kg | |
|---|---|---|
| Static load capacity (sleep surface) | 500 kg | |
| Recommended mattress weight capacity | 70 kg | |
| Suitable user count | 2 | |
| Frame joint static load rating | 300 kg per connection | |
| Upholstery abrasion resistance | 40000 cycles | |
| Expected service life | 10 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery fabric | Dark matte woven polyester fabric, 320gsm | |
|---|---|---|
| Inner support frame | Kiln-dried solid pine wood, 30mm thick board | |
| Headboard padding | High-density polyurethane foam, 40kg/m3 density, 80mm thickness | |
| Side rail padding | High-density polyurethane foam, 35kg/m3 density, 30mm thickness | |
| Decorative accents | Antique bronze finished brushed metal, 2mm thick plate | |
| Mattress support slats | Laminated birch wood slats, 12mm thick, 60mm wide, 80mm spacing | |
| Corner connection hardware | Zinc-plated steel brackets, 3mm thick | |
| Floor protection pads | Felt glides, 5mm thick, 30mm diameter | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support type | Slatted platform base, no box spring required | |
|---|---|---|
| Headboard design | Curved padded segmented headboard, provides back support for seated reading | |
| Assembly requirement | Knock-down assembly, hardware included for headboard and rail connection | |
| Decorative trim | Fixed bronze metal accent plates at all four lower frame corners | |
| Edge support | Reinforced padded side rails prevent mattress slippage | |
| Floor compatibility | Felt glides suitable for hardwood, tile and carpeted floors | |
| Bedding fit | Low profile base allows standard fitted sheets with 350mm pocket depth | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Suitable for 18sqm bedrooms, low profile design creates open visual space | |
|---|---|---|
| Modern themed interiors | Matches minimalist, contemporary and industrial bedroom decor styles | |
| Guest bedroom use | Queen size comfortably accommodates visiting adult guests | |
| Low-ceiling spaces | Low platform height suits attic or reduced ceiling height rooms | |
| Hard surface flooring | Felt glides protect hardwood, laminate and tile floors from scratches |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture, beds and mattresses, safety and strength test requirements |
|---|
Standards applicable to China-market projects
| GB 18584-2001 | Indoor decoration material, formaldehyde emission limit for wood furniture |
|---|
This product must meet the following technical requirements: 1. GB 18584-2001: Indoor decoration material, formaldehyde emission limit for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
