Automatic mm / inch conversion · Core engineering specifications
| Overall outer dimensions | 2270 x 2030 x 1210 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1210 mm | |
| Side rail height from floor | 350 mm | |
| Sleeping surface height from floor | 300 mm | |
| Wingback side extension width | 80 mm | |
| Headboard inset panel dimensions per section | 850 x 400 mm | |
| Under-bed ground clearance | 50 mm | |
| Side rail thickness | 60 mm | |
| Slat width | 70 mm | |
| Slat spacing gap | 60 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 363 kg | |
|---|---|---|
| Recommended number of users | 2 | |
| Center support leg count | 3 | |
| Wood slat count | 14 | |
| Upholstery abrasion resistance | 30000 cycles | |
| Headboard padding foam density | 45 kg/m³ | |
| Foam compression set resistance | 90% rebound | |
| Warranty period | 5 years | |
| Available color option count | 6 | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Internal structural frame | MDF and plywood composite, 18mm thickness | |
|---|---|---|
| Headboard and rail padding | High-density polyurethane foam, 50mm thickness on headboard | |
| Outer upholstery (frame, headboard outer) | Slate blue PU faux leather, 0.8mm thickness | |
| Headboard inset panel upholstery | Grey textured woven polyester fabric, 350gsm weight | |
| Mattress support slats | Solid poplar wood, 12mm thickness, sanded smooth finish | |
| Center support beam | Solid engineered wood, 30mm thickness, with metal support legs | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts, 8mm diameter | |
| Base foot pads | Non-slip black plastic floor protectors, 20mm height | |
| Seam construction | Reinforced polyester stitching, 8 stitches per inch | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Wooden slat platform, no box spring required for all standard mattress types | |
|---|---|---|
| Headboard function | Padded wingback design provides wall protection and seated back support for reading in bed | |
| Assembly mechanism | Knockdown construction with included hex key hardware, pre-drilled alignment holes | |
| Floor protection | Integrated non-slip foot pads prevent floor scuffing and uneven floor wobble | |
| Placement flexibility | Low-profile zero-footboard design allows placement at foot of room without circulation obstruction | |
| Mattress retention | Raised upholstered side rails prevent mattress shifting during use | |
| Center support adjustment | Threaded metal support legs allow height adjustment to eliminate slat sag | |
| Upholstery maintenance | Faux leather outer surfaces wipe clean with damp cloth; fabric insets are spot-clean only | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, modern minimalist or contemporary interior design schemes | |
|---|---|---|
| Target user group | Adult couples or individual users seeking a low-profile padded bed without box spring | |
| Recommended pairing | Matching slate blue two-drawer nightstands placed symmetrically on either side of headboard | |
| Mattress compatibility | Memory foam, latex, innerspring, and hybrid mattresses 350 mm thick | |
| Space requirement recommendation | Minimum bedroom width of 3000mm to accommodate nightstands and bedside circulation | |
| Placement orientation | Headboard mounted flush against wall, open foot end facing room circulation path | |
| Style complement | Pairs with neutral-toned bedding, wood-look herringbone flooring, and warm metallic pendant lighting |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture - Ignitability assessment for smouldering cigarette source | |
| EN 747:2012+A1:2015 | Domestic furniture - Beds and mattresses - Test methods for strength and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural safety | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances in wood furniture | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture beds |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural safety; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances in wood furniture; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture beds; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
