Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1820 x 2290 x 1130 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1130 mm | |
| Mattress support surface height from floor | 420 mm | |
| Footboard height from floor | 350 mm | |
| Underbed storage clearance height | 230 mm | |
| Headboard padding thickness | 120 mm | |
| Side rail width | 80 mm | |
| Slat support width | 70 mm | |
| Slat spacing gap | 60 mm | |
| Leg diameter | 20 mm | |
| Footboard pull handle length | 180 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 500 kg | |
|---|---|---|
| Frame net weight | 110 kg | |
| Underbed storage volume | 540 L | |
| Recommended user count | 2 | |
| Foam padding density | 40 kg/m³ | |
| Slat static load per unit | 50 kg | |
| Upholstery abrasion resistance | 50000 cycles | |
| Warranty period | 3 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard and frame upholstery | Camel tan top-grain leather match surface | |
|---|---|---|
| Headboard padding | 40kg/m³ high-density polyurethane foam | |
| Inner structural frame | Solid kiln-dried pine + engineered wood panels | |
| Mattress support system | 15mm thick steel-wood slat base with EVA mute strips | |
| Support legs | 1.2mm thick matte black powder-coated steel legs | |
| Footboard hardware | Matte black metal pull handle for storage access | |
| Storage lifting mechanism | Hydraulic gas strut lift system | |
| Connection hardware | Zinc-plated steel bolts and corner brackets | |
| Side rail finish | Matching upholstery wrapped over wood frame | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Lift-up underbed storage | Footboard handle actuates hydraulic lift to access full underbed area | |
|---|---|---|
| No box spring required | Slat base directly supports all standard mattress types | |
| Noise reduction design | EVA padding strips on slats eliminate friction squeaks | |
| Headboard back support | Segmented padded sections support upright seated reading or media use | |
| KD flat-pack assembly | Frame assembles with included hardware without specialized tools | |
| Edge protection | Upholstered side and foot rails prevent impact injuries | |
| Floor protection | Plastic glides on leg bases prevent hard floor scratching | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential use | Master bedrooms for modern minimalist or wabi-sabi interior schemes | |
|---|---|---|
| Secondary hospitality use | High-end hotel guest rooms and serviced apartments | |
| Space-saving application | Small to medium bedrooms requiring integrated underbed storage | |
| Seated relaxation use | Bedrooms used for reading or media consumption in bed | |
| Matching configuration | Pairs with matching camel tan upholstered nightstands and low-profile area rugs | |
| Mattress compatibility | Fits 1800x2000mm spring, memory foam, or hybrid mattresses up to 300mm thick |
EU Market Access Requirements* EN Standards
| EN 747:2012+A1:2015 | Furniture - Bunk beds and high beds - Safety requirements, structural safety reference | |
|---|---|---|
| EN 1334:1996 | Domestic furniture - Beds and mattresses - Test methods for strength and durability | |
| EN 1021-1:2014 | Upholstered furniture ignitability resistance (cigarette test) safety reference |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame components | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior decoration wooden furniture,Acceptancereference | |
| GB/T 16799-2008 | Leather for furniture, applicable to upholstery material verification | |
| GB/T 19001-2016 | Quality management system reference for production consistency |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame components; 2. GB 18584-2001: Formaldehyde emission limit for interior decoration wooden furniture,Acceptancereference; 3. GB/T 16799-2008: Leather for furniture, applicable to upholstery material verification; 4. GB/T 19001-2016: Quality management system reference for production consistency; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
