Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 2200 x 1100 mm | |
|---|---|---|
| Headboard height | 1100 mm | |
| Headboard thickness | 180 mm | |
| Bed base height | 380 mm | |
| Recommended mattress thickness | 380 mm | |
| Under-slat storage depth | 300 mm | |
| Floor clearance under base | 120 mm | |
| Slat width | 70 mm | |
| Slat spacing | 80 mm | |
| Recessed headboard channel length | 1200 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 450 kg | |
|---|---|---|
| Net weight (assembled) | 120 kg | |
| Storage compartment volume | 0.75 m³ | |
| Recommended user weight per side | 150 kg | |
| Hydraulic lift mechanism cycle rating | 10000 cycles | |
| Seam stitch tensile strength | 120 N | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard main panel upholstery | Textured cream boucle fabric | |
|---|---|---|
| Headboard trim/bed base outer upholstery | Smooth taupe faux leather | |
| Headboard padding | 40mm high-resilience polyurethane foam | |
| Bed base frame core | 18mm E0-grade particleboard with metal bracing | |
| Support slats | 12mm thick laminated birch plywood | |
| Lift mechanism hardware | Carbon steel gas struts with zinc-plated hinges | |
| Footrest detail | Faux leather stitched pull strap | |
| Base support feet | 20mm diameter black PP plastic glides | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Under-bed storage access | Hydraulic lift-up mattress platform | |
|---|---|---|
| Headboard integrated power | Dual AC outlets with USB-A/USB-C ports | |
| Mattress support system | No box spring required | |
| Noise-reduction design | EVA anti-slip pads on all slat contact points | |
| Headboard design function | Recessed horizontal channel acts as small ledge | |
| Base edge protection | Reinforced faux leather binding at all corners | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary use space | Primary residential bedroom | |
|---|---|---|
| Target users | Adults seeking storage-integrated, device-charging bedroom furniture | |
| Recommended configuration | Pair with 300 mm thick hybrid or memory foam mattress | |
| Design style fit | Modern, minimalist, light-luxury interior schemes | |
| Functional benefit for small spaces | Eliminates need for separate dressers | |
| Cleaning suitability | Smooth faux leather base and low floor clearance |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses, safety and strength requirements | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating, stability and structural strength for upholstered components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame and panel safety | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde emission for wooden furniture, mandatory E0 compliance requirement | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, beds and mattresses |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame and panel safety; 2. GB 18584-2001: Limit of formaldehyde emission for wooden furniture, mandatory E0 compliance requirement; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, beds and mattresses; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
