Automatic mm / inch conversion · Core engineering specifications
| Overall external dimensions | 2120 x 1880 x 1380 mm | |
|---|---|---|
| Internal mattress fit dimensions | 1800 x 2000 mm | |
| Headboard total height | 1380 mm | |
| Footboard height | 460 mm | |
| Side rail height above floor | 330 mm | |
| Recommended mattress thickness | 510 mm | |
| Gold foot leg height | 100 mm | |
| Wingback headboard protrusion width | 2400 mm | |
| Under-bed clearance height | 120 mm | |
| Center support beam count | 5 | |
| Slat count for mattress support | 15 | |
| Slat spacing gap | 70 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total bed static load capacity | 500 kg | |
|---|---|---|
| Net weight (bed frame only, no mattress) | 87 kg | |
| Seated back support load on headboard | 150 kg | |
| Recommended user count | 2 | |
| Frame structural warranty period | 5 years | |
| Upholstery abrasion resistance | 50000 cycles | |
| Foam padding density (headboard/footboard) | 38 kg/m³ | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery fabric | Smooth light off-white faux leather | |
|---|---|---|
| Internal frame structure | Solid mahogany wood + multi-layer plywood | |
| Headboard/footboard padding | 38kg/m³ high-density polyurethane foam + polyfiber fill | |
| Gold accent trim | Gold-plated metal strip trim along wing edges and footboard center | |
| Support legs | Tapered gold-plated steel legs | |
| Mattress support slats | 15mm thick solid poplar wood slats with EVA noise-reduction pads | |
| Side rail panels | 25mm thick MDF with full upholstered wrapping | |
| Connecting hardware | Zinc-plated steel bolts and corner brackets | |
| Headboard tufting details | Faux leather covered pull buttons with gold base accent | |
| Footboard center panel | Quilted honeycomb-stitched faux leather panel | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Wood slat platform, no box spring required | |
|---|---|---|
| Noise-reduction design | EVA foam pads between slats and frame rails | |
| Knock-down assembly | Flat-packed components with included hardware and instructions | |
| Headboard seated support | Padded wingback design supports upright seated posture | |
| Under-bed access | 120mm floor clearance allows robotic vacuum cleaning | |
| Matching nightstand compatibility | Pre-coordinated finish and gold hardware for paired 2-drawer nightstands | |
| Fixed structural design | No moving storage parts, lift mechanisms, or adjustable components | |
| Mattress retention design | Raised side rail lip prevents mattress sliding | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms | |
|---|---|---|
| Matching interior style | Light luxury, modern American, glam-inspired bedrooms | |
| Recommended supporting furniture | Matching 2-drawer white nightstands, upholstered bench, low-pile area rug | |
| Suitable mattress types | Memory foam, latex, innerspring, hybrid mattresses up to 510mm thick | |
| Target user group | Adult homeowners, boutique hotel guest rooms, high-end rental properties | |
| Recommended placement | Centered against feature wall with 600mm clearance on both sides |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Applicable European standard for domestic furniture: beds, safety and strength requirements | |
|---|---|---|
| EN 1022:2005 | Applicable standard for furniture seating and bed stability verification | |
| EN 14988:2007 | Applicable standard for children's and adult bed mechanical performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable general technical standard for wooden furniture, frame and panel requirements | |
|---|---|---|
| GB 18584-2001 | Applicable indoor decoration material limit standard for formaldehyde emission in wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable general technical standard for wooden furniture, frame and panel requirements; 2. GB 18584-2001: Applicable indoor decoration material limit standard for formaldehyde emission in wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
