Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (Queen size) | 1750 x 2240 x 1130 mm | |
|---|---|---|
| Headboard overall height | 1130 mm | |
| Headboard padding thickness | 97 mm | |
| Side rail height (floor to rail top) | 356 mm | |
| Slat support height (floor to slat surface) | 285 mm | |
| Interior mattress fit width | 1530 mm | |
| Interior mattress fit depth | 2030 mm | |
| Footboard height (floor to footboard top) | 356 mm | |
| Rattan inlay trim width on headboard | 32 mm | |
| Clearance between floor and frame base | 0 mm | |
| Recommended maximum mattress thickness | 305 mm | |
| Center support beam span width | 102 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity (mattress + occupants) | 318 kg | |
|---|---|---|
| Product net weight | 52 kg | |
| Number of support slats | 14 | |
| Slat spacing (clear gap between adjacent slats) | 76 mm | |
| Center support leg count | 3 | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Seam stitch tensile strength | 136 N | |
| Noise emission under normal movement | 30 dB | |
| Limited warranty period | 1 year | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard outer wrap upholstery | Cream looped boucle 100% polyester fabric | |
|---|---|---|
| Headboard inner panel, side rails, footboard upholstery | Woven polyester fabric with vertical black/tan stripes | |
| Headboard decorative inlay trim | Natural rattan webbing | |
| Internal structural frame | 18mm thick plywood and engineered wood | |
| Upholstery padding material | 32kg/m3 density high-resilience polyurethane foam | |
| Support slats | 12mm thick solid pine wood slats | |
| Frame connecting hardware | Zinc-plated steel bolts and barrel nuts | |
| Optional matching decorative pillows | Stripe-matched polyester upholstery with 28kg/m3 foam fill | |
| Surface finish on rattan trim | Clear matte lacquer sealant | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Support system design | Slatted platform base compatible with all foam, hybrid, and spring mattresses without box spring | |
|---|---|---|
| Headboard functional support | Padded curved wraparound design provides lumbar and neck support for seated reading in bed | |
| Assembly requirement | Flat-pack assembly with included hex key and hardware, no special tools required | |
| Under-bed storage access | No built-in under-bed storage or clearance, floor-skimming frame eliminates dust buildup under structure | |
| Corner safety design | Fully rounded soft edges on headboard, footboard and side rails to eliminate sharp impact points | |
| Slat attachment mechanism | Slats pre-mounted to central support straps to reduce assembly time and prevent movement | |
| Mattress retention | Raised upholstered rail lip on all sides prevents mattress shifting during use | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential primary bedroom use | Ideal for modern, contemporary, or organic-inspired bedroom interiors as a statement focal point | |
|---|---|---|
| Recommended mattress pairing | Works with 300 mm thick memory foam, hybrid, or innerspring mattresses for low-profile aesthetic | |
| User suitability | Designed for 2 adult occupants in Queen size configuration for daily long-term residential use | |
| Recommended complementary furniture | Pairs with low-profile dressers and nightstands with natural rattan or boucle textural accents | |
| Space requirement | Requires minimum 300mm clearance on sides and foot of bed for easy movement and bed making | |
| Care and maintenance | Upholstery requires regular vacuuming and spot cleaning with water-based fabric cleaner only |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods, applicable to structural safety | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette, applicable to all fabric components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural frame performance and dimensional tolerances | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission from engineered wood components | |
| GB/T 19845-2005 | Upholstered furniture durability test methods, applicable to static load and fatigue testing of bed structure |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural frame performance and dimensional tolerances; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission from engineered wood components; 3. GB/T 19845-2005: Upholstered furniture durability test methods, applicable to static load and fatigue testing of bed structure; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
