Automatic mm / inch conversion · Core engineering specifications
| Overall footprint (W x L x H) | 2000 x 2200 x 1050 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1050 mm | |
| Under-bed floor clearance | 160 mm | |
| Headboard cushion thickness | 220 mm | |
| Slat spacing | 15 mm | |
| Slat frame thickness | 150 mm | |
| Footboard edge height from floor | 300 mm | |
| Under-bed storage compartment depth | 250 mm | |
| LED light strip distance from floor | 80 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 800 kg | |
|---|---|---|
| Recommended mattress thickness | 300 mm | |
| Net weight (bed frame only) | 100 kg | |
| Anti-squeak noise rating | Whisper quiet | |
| Support slat count | 15 | |
| Center support leg count | 13 | |
| LED strip rated lifespan | 50000 hours | |
| Frame warranty period | 20 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery (contact surface) | Top-grain cowhide with soft wrinkle finish | |
|---|---|---|
| Headboard cushion fill | High-density resilient foam (45D) | |
| Inner bed frame | Kiln-dried solid pine wood | |
| Support slats | Laminated beech wood slats with steel cross-bracing | |
| Platform side rails | Powder-coated steel frame with matte white finish | |
| Under-bed light strip | Low-voltage 3000K warm white LED strip | |
| Hardware connectors | Zinc-plated steel bolts and corner brackets | |
| Storage compartment base | Medium-density fiberboard with moisture-resistant lining | |
| Anti-slip mattress pad | Non-woven fabric with anti-slip silicone dots | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Under-bed storage access | Gas-lift platform activated by foot-end black metal pull handle | |
|---|---|---|
| Under-bed LED lighting | Motion-activated warm white ambient glow | |
| Floating visual effect | Hidden recessed support legs positioned inward from frame edge | |
| Robot vacuum compatibility | 160mm under-bed clearance allows most robotic cleaners to pass freely | |
| Noise-dampening design | EVA sponge strips applied between all metal and wood contact points | |
| Wall-leaning installation | Headboard sits flush against wall without permanent wall fixation | |
| Anti-tipping stability | Triangular hidden steel support brackets under mid-frame | |
| Box spring elimination | Closely spaced slats provide direct mattress support | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, modern minimalist or light luxury interior schemes | |
|---|---|---|
| Target user group | Adult consumers seeking soft upholstered headboard support and hidden storage | |
| Recommended configuration pairing | Match with two floating acrylic-leg nightstands for coordinated aesthetic | |
| Robot vacuum friendly use | Suitable for homes equipped with robotic floor cleaners due to high under-bed clearance | |
| Low-light nighttime use | Ideal for users who prefer soft ambient navigation lighting without overhead lights | |
| Space-efficient storage | Suitable for small to medium bedrooms needing hidden linen and bedding storage | |
| Mattress compatibility | Pairs with spring, memory foam, latex, or hybrid mattresses 30 cm thick |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 13150:2004 | Work surfaces for domestic and kitchen use, applicable to bed frame edge performance | |
| EN 62471:2008 | Photobiological safety of LED lamps and lamp systems used in furniture | |
| EN 1022:2005 | Domestic furniture - Seating - Determination of stability, applicable to bed frame anti-tip design |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood frame components | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 22800-2009 | Upholstered furniture general test methods for seating and bedding products | |
| GB 7000.204-2008 | Safety requirements for decorative LED lighting fixtures used in furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood frame components; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 22800-2009: Upholstered furniture general test methods for seating and bedding products; 4. GB 7000.204-2008: Safety requirements for decorative LED lighting fixtures used in furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
