| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 2200 x 1210 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height | 1210 mm | |
| Floor to slat support height | 330 mm | |
| Metal support leg height | 140 mm | |
| Underbed storage compartment depth | 250 mm | |
| Slat support thickness | 25 mm | |
| Slat spacing | 70 mm | |
| Foot rail pull handle height | 310 mm | |
| Compatible mattress thickness | 220 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 363 kg | |
|---|---|---|
| Gas strut lift capacity | 180 kg | |
| Lift mechanism cycle durability | 100000 cycles | |
| Net bed weight | 85 kg | |
| Headboard padding density | 45 kg/m³ | |
| Upholstery abrasion resistance | 50000 cycles | |
| Recommended user weight per side | 150 kg | |
| Storage compartment load limit | 100 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard outer frame upholstery | Orange matte faux leather, stitched edge trim | |
|---|---|---|
| Headboard cushion panels | Off-white padded faux leather, segmented double cushion design | |
| Headboard internal padding | 45kg/m³ high-resilience polyurethane foam, 80mm thick | |
| Bed base storage frame | E1-grade engineered wood, wrapped in matching orange faux leather | |
| Slat support system | Solid pine wood slats, connected anti-slip slat roll | |
| Lift mechanism hardware | Cold-rolled steel frame, dual pneumatic gas struts, anti-fall safety lock | |
| Support legs | Powder-coated black angled steel legs, 6 total support points | |
| Foot rail pull handle | Black metal recessed pull, integrated into foot rail top edge | |
| Joint hardware | Zinc-plated steel bolts and barrel nuts, anti-loosening lock washers | |
| Slat noise reduction strips | EPDM rubber mute strips between slats and frame | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Lift-up underbed storage access | Foot-rail pull activates dual gas struts to lift slat deck for full storage access | |
|---|---|---|
| Anti-fall safety lock | Mechanical lock engages automatically when deck is fully lifted to prevent accidental closure | |
| Slow-close damping | Gas struts provide controlled descent when lowering deck to avoid slamming | |
| Anti-slip mattress retainer | Raised lip at head and foot of slat deck prevents mattress sliding during lift operation | |
| No box spring support | Closely spaced solid wood slats support mattress directly without separate foundation | |
| Knock-down assembly | Frame disassembles into headboard, side rails, lift base, and slat pack for flat-pack delivery | |
| Center support bracing | Steel cross bracing and center leg eliminate slat sag under heavy mattress load | |
| Seated back support | Tall padded segmented headboard provides lumbar and back support for upright sitting in bed | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Packaging notes | All components padded with foam corners, wrapped in corrugated cardboard for transit protection | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, paired with matching two-drawer nightstands | |
|---|---|---|
| Target user group | Adult couples requiring hidden underbed storage for bedding and personal items | |
| Recommended interior style | Modern light luxury, contemporary minimalist, warm neutral tone bedroom schemes | |
| Aisle clearance requirement | 600 mm minimum clearance around bed sides for access and storage operation | |
| Bedding configuration | Pair with 1800x2000mm spring or foam mattress up to 220mm thick | |
| Placement note | Position with 300mm clearance at foot of bed to allow full lift of storage deck |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Furniture - Beds and mattresses - Safety requirements and test methods, applicable for structural safety | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignition resistance (smoldering cigarette) for upholstery materials | |
| EN 312:2010 | Particleboard specifications for engineered wood frame components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and structural components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for engineered wood components, E1 grade required | |
| GB/T 28007-2011 | General technical requirements for upholstered beds, applicable to padding and structural durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and structural components; 2. GB 18580-2017: Formaldehyde emission limit for engineered wood components, E1 grade required; 3. GB/T 28007-2011: General technical requirements for upholstered beds, applicable to padding and structural durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
