Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2270 x 2340 x 1050 mm | |
|---|---|---|
| mattress support platform dimensions | 2030 x 1930 mm | |
| headboard height from platform surface | 640 mm | |
| platform base height from floor | 410 mm | |
| recommended mattress thickness | 410 mm | |
| side rail upholstered panel thickness | 120 mm | |
| under-bed clearance | 0 mm | |
| headboard panel depth | 200 mm | |
| side rail overhang beyond mattress | 120 mm per side | |
| slat width | 70 mm | |
| slat spacing | 70 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| total static weight capacity | 800 kg | |
|---|---|---|
| net product weight | 77 kg | |
| recommended maximum user weight per side | 180 kg | |
| mattress type compatibility | memory foam, latex, innerspring, hybrid | |
| upholstery abrasion resistance | 30000 double rubs | |
| foam padding density | 28 kg/m³ | |
| foam rebound rate | 60% | |
| structural durability cycle count | 10000 load cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| external upholstery | 100% polyester velvet fabric, slate blue finish | |
|---|---|---|
| headboard cushion padding | 28 kg/m³ polyurethane foam wrapped in polyester wadding | |
| side rail padding | 25 mm thick polyurethane foam under velvet upholstery | |
| internal frame core | Kiln-dried solid pine and 18mm thick MDF panels | |
| slat support system | 12mm thick bent plywood slats mounted on EVA noise-dampening pads | |
| center support beam | 30mm thick engineered wood beam running full length of frame | |
| connection hardware | Zinc-plated steel bolts, barrel nuts, and corner brackets | |
| seam construction | Reinforced stitched seams with 8 stitches per inch | |
| base bottom layer | Non-woven polypropylene dust cover | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| slat support system | Evenly spaced plywood slats eliminate need for separate box spring | |
|---|---|---|
| padded headboard design | Plump oversized upholstered back cushions support upright seated posture for reading | |
| enclosed wrapped base | Floor-resting fully upholstered base eliminates exposed legs and under-bed gaps | |
| noise-reduction construction | EVA padded slat mounts and secured hardware prevent squeaking during movement | |
| knock-down assembly | Tool-included assembly with pre-drilled frame sections and aligned hardware | |
| edge support | Reinforced padded side rails prevent mattress edge sag when sitting on bed perimeter | |
| cushion positioning | Loose headboard cushions can be rearranged for custom back support | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| primary application space | Residential master bedrooms, contemporary minimalist interiors | |
|---|---|---|
| target user group | Adult sleepers seeking soft, modern low-profile bed design without visible hardware | |
| complementary design pairing | Pairs with low-profile bedroom case goods and soft textural bedding | |
| recommended mattress pairing | 16inch thick all-foam or hybrid mattress for flush alignment with side rails | |
| installation requirement | Suitable for placement on low-pile carpet, hardwood, or luxury vinyl flooring | |
| style alignment | Fits modern, wabi-sabi, relaxed casual, and contemporary luxury bedroom designs |
EU Market Access Requirements* EN Standards
| EN 1725:2012 | Applicable for safety, strength and durability of domestic beds | |
|---|---|---|
| EN 1021-1:2014 | Applicable for upholstered furniture ignition resistance from smoldering cigarette |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden furniture strength and stability | |
|---|---|---|
| GB 18580-2017 | Applicable for formaldehyde emission limits of engineered wood used in frame | |
| GB/T 1952.2-2011 | Applicable for safety and durability requirements of upholstered bed furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden furniture strength and stability; 2. GB 18580-2017: Applicable for formaldehyde emission limits of engineered wood used in frame; 3. GB/T 1952.2-2011: Applicable for safety and durability requirements of upholstered bed furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
