Automatic mm / inch conversion · Core engineering specifications
| Overall bed dimensions | 2032 x 2159 x 1422 mm | |
|---|---|---|
| Headboard height above slat surface | 1118 mm | |
| Under-bed storage compartment internal height | 305 mm | |
| Recommended mattress thickness | 279 mm | |
| Matching nightstand dimensions | 470 x 390 x 559 mm | |
| Nightstand drawer internal dimensions | 390 x 330 x 140 mm | |
| Slat support width between side rails | 1930 mm | |
| Floor clearance under side rails | 152 mm | |
| Footboard storage pull handle length | 150 mm | |
| Nightstand tabletop thickness | 18 mm | |
| Headboard padding thickness | 76 mm | |
| Gold bed leg height | 152 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Bed static weight capacity | 363 kg | |
|---|---|---|
| Nightstand tabletop static load capacity | 32 kg | |
| Bed net weight | 69 kg | |
| Under-bed storage compartment volume | 0.38 m³ | |
| Slat count for mattress support | 14 pcs | |
| Center support leg count | 3 pcs | |
| Recommended user count | 2 adults | |
| Nightstand drawer slide load rating | 15 kg per drawer | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Soft woven velvet fabric over 25kg/m³ high-resilience polyurethane foam | |
|---|---|---|
| Bed inner frame | Combination solid pine lumber and CARB P2 grade MDF composite | |
| Support slats | 18mm thick laminated bent wood slats, spaced 70mm apart | |
| Bed legs | 1.5mm thick gold powder-coated carbon steel, tapered profile | |
| Nightstand carcass | 15mm thick CARB P2 grade MDF with matte white lacquer finish | |
| Nightstand hardware | Gold brushed zinc alloy drawer pulls, pre-lubricated steel drawer slides | |
| Footboard pull handle | Matte black coated steel pull, mounted flush to footboard panel | |
| Headboard internal frame | 25mm thick plywood structural backing for tufted channels | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Under-bed storage access | Footboard-mounted pull-out storage drawer on steel roller slides, full extension opening | |
|---|---|---|
| Mattress support | Wooden slat platform system, no box spring required for mattress support | |
| Nightstand drawer operation | Two stacked drawers with smooth full-extension metal glides, soft-close optional | |
| Headboard design | Fixed vertical channel-tufted padded headboard, no tilt or height adjustment | |
| Assembly requirement | Knock-down assembly with included hex key and hardware set, 2-person assembly | |
| Floor protection | Plastic glide inserts fitted to base of all gold metal legs to prevent floor scratching | |
| Set configurability | Bed available as standalone unit or bundled with 1 or 2 matching nightstands | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary use space | Residential master bedrooms, light luxury/modern style interior designs | |
|---|---|---|
| Target user group | Adult users seeking hidden storage and soft upholstered headboard comfort | |
| Recommended matching furniture | Matching 2-drawer nightstand, 11inch thick hybrid or memory foam mattress | |
| Suitable flooring types | Hardwood, laminate, tile, or low-pile carpeted bedroom floors | |
| Design style compatibility | Works with modern minimalist, light luxury, French contemporary, and cream-style decor | |
| Storage advantage | Ideal for small to medium bedrooms requiring concealed bedding/seasonal item storage |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods, applicable to structural stability | |
|---|---|---|
| EN 71-3:2019 | Safety of toys - Migration of certain elements, applicable to finish heavy metal limits for residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame and nightstand structural testing | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, applicable to composite panel emissions | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture mattresses, applicable to bed support performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame and nightstand structural testing; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, applicable to composite panel emissions; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture mattresses, applicable to bed support performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
