Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1880 x 2220 x 930 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height above slat surface | 740 mm | |
| Floor to slat support surface height | 320 mm | |
| Under-bed ground clearance | 187 mm | |
| Headboard panel thickness | 180 mm | |
| Platform side rail thickness | 60 mm | |
| Support slat width | 70 mm | |
| Support slat spacing | 65 mm | |
| Acrylic support leg height | 187 mm | |
| Number of support legs | 7 | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 363 kg | |
|---|---|---|
| Net product weight | 85 kg | |
| Headboard padding foam density | 35 kg/m³ | |
| Support slat static load per slat | 25 kg | |
| LED light strip lifespan | 30000 hours | |
| Squeak-free use cycle rating | 10000 use cycles | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Recommended maximum user weight per sleeper | 150 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | White soft woven boucle/velvet blend fabric | |
|---|---|---|
| Headboard padding | High-resilience polyurethane foam | |
| Internal support frame | 1.2mm thick carbon steel tube | |
| Mattress support slats | 12mm thick laminated poplar wood slats | |
| Support legs | Clear transparent acrylic | |
| Under-bed lighting | Flexible LED strip with warm white 3000K output | |
| Frame hardware connectors | Zinc-plated steel bolts and brackets | |
| Side rail upholstery | Matching white fabric over engineered wood core | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Under-bed ambient lighting | Warm white LED strip with wall switch control | |
|---|---|---|
| Mattress support | Fixed wooden slat system, no box spring required | |
| Assembly requirement | Adult assembly with included hardware tools | |
| Center support structure | Full-length steel center rail with middle support leg | |
| Edge protection | Padded upholstered side and foot rails | |
| Under-bed clearance access | 187mm open space below frame | |
| Headboard mounting | Fixed wall-aligned attachment to bed frame | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 3 | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedroom | |
|---|---|---|
| Secondary application space | Small apartment guest bedroom | |
| Target user group | Adult consumers seeking modern minimalist bedroom furniture | |
| Recommended matching furniture | Matching acrylic-leg nightstands, low-pile area rug | |
| Recommended mattress type | 300 mm thick memory foam, latex or spring mattress | |
| Installation note | Place against flat wall with 50mm clearance for headboard alignment | |
| Style compatibility | Cream style, French modern, minimalist interior design schemes |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance to smouldering cigarette source |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for indoor air quality | |
| GB/T 24821-2009 | General technical requirements for upholstered furniture beds, applicable for soft parts |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for indoor air quality; 3. GB/T 24821-2009: General technical requirements for upholstered furniture beds, applicable for soft parts; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
