| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1880 x 2240 x 1050 mm | |
|---|---|---|
| Internal mattress fit size | 1800 x 2000 mm | |
| Headboard height from floor | 1050 mm | |
| Headboard padding thickness | 80 mm | |
| Side rail height from floor | 350 mm | |
| Footboard height from floor | 350 mm | |
| Floor clearance under frame | 50 mm | |
| Recommended mattress thickness | 305 mm | |
| Side rail thickness | 120 mm | |
| Footboard radius (rounded end) | 180 mm | |
| Headboard corner radius | 60 mm | |
| Center support beam height | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 318 kg | |
|---|---|---|
| Net product weight | 76 kg | |
| Slat static point load capacity | 120 kg | |
| Recommended number of users | 2 adults | |
| Upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Padding compression recovery rate | 92% | |
| Slat spacing for mattress support | 75 mm | |
| Warranty period (frame) | 3 years | |
| Fabric warranty coverage | 0 years | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| External upholstery fabric | Textured woven olive-brown polyester fabric, 350gsm | |
|---|---|---|
| Internal load-bearing frame | 18mm thick plywood and solid pine wood, steel brace reinforcements | |
| Headboard and frame padding | 25kg/m3 density polyester fiber fill, wrapped over frame edges | |
| Support slat system | 12mm thick curved solid birch slats, 14 slats per bed | |
| Center support structure | 40mm x 60mm solid wood beam with 2 central support legs | |
| Floor support feet | 20mm diameter plastic floor glides, 50mm height, non-marking | |
| Edge trim binding | Matching fabric stitched edge binding, 8mm seam pitch | |
| Hardware connectors | Zinc-plated steel bolts, dowels and barrel nuts for knock-down assembly | |
| Slat anti-noise padding | EVA foam strips between slats and support rails | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Wood slat platform design, no box spring required for direct mattress placement | |
|---|---|---|
| Collision protection | Fully rounded padded edges on headboard corners, side rails and footboard | |
| Floor protection | Non-marking plastic glides on all support feet to prevent hard floor scratching | |
| Assembly structure | Knock-down flat-pack design with included hex key and illustrated instructions | |
| Underbed airflow | Evenly spaced wood slats with 50mm floor clearance to promote mattress ventilation | |
| Cleaning compatibility | Spot-clean only with mild fabric detergent, no machine washing of upholstery | |
| Position stability | Fixed non-rocking frame structure with tightened bolted connections and central supports | |
| Noise reduction | EVA buffer pads between slats and rails to eliminate squeaking during use | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary residential use | Master bedrooms and guest bedrooms for modern, wabi-sabi or mid-century modern interiors | |
|---|---|---|
| Space suitability | Small to medium sized bedrooms, low-profile design reduces visual bulk in compact rooms | |
| User compatibility | Adult users including couples, suitable for users who prefer low bed access height | |
| Recommended pairing | Pair with 300 mm thick memory foam, hybrid or spring mattresses for optimal comfort | |
| Flooring compatibility | Suitable for hardwood, laminate, tile and carpeted floors with non-marking glides | |
| Style coordination | Coordinates with warm neutral, earth tone and muted fabric bedroom furniture sets |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - beds and mattresses, safety and strength performance requirements | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture - ignitability resistance to smouldering cigarette sources |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame structural integrity | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances of wood furniture | |
| GB/T 19822-2005 | Test methods for furniture structural strength, applicable to static load and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame structural integrity; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances of wood furniture; 3. GB/T 19822-2005: Test methods for furniture structural strength, applicable to static load and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
