Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2870 x 2180 x 1120 mm | |
|---|---|---|
| Sleeping surface width (Queen size) | 1530 mm | |
| Sleeping surface length | 2030 mm | |
| Headboard height from platform surface | 880 mm | |
| Integrated side shelf surface width | 860 mm | |
| Integrated side shelf depth from bed edge | 450 mm | |
| Underbed clearance | 120 mm | |
| Support leg height | 120 mm | |
| Recommended mattress thickness | 300 mm | |
| Slat spacing | 70 mm | |
| Slat count | 28 | |
| Side table top diameter | 400 mm | |
| Side Rail Thickness | 40 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Maximum single user weight | 150 kg | |
| Net weight (queen size) | 60 kg | |
| Slat static load rating per slat | 25 kg | |
| Upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Seam stitch pitch | 3 stitches per cm | |
| Warranty period | 1 year | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Pink crushed velvet fabric | |
|---|---|---|
| Headboard padding | 25mm high-density polyurethane foam | |
| Frame core structure | 18mm Plywood and MDF composite | |
| Support slats | 12mm thick solid birch wood slats | |
| Support legs | 25mm diameter black powder-coated steel legs | |
| Integrated side table top | 8mm thick tinted tempered glass | |
| Side table support post | 20mm diameter black powder-coated steel | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts | |
| Underbed frame reinforcement | 1.2mm thick steel center support rail | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support | Slatted platform base, no box spring required | |
|---|---|---|
| Integrated nightstand shelf | Extended curved left platform surface | |
| Attached side table | Fixed round glass-top table on the shelf | |
| Wingback headboard | Split two-panel curved padded design | |
| Noise-reduction slat mounting | Velcro strip slat attachments | |
| Assembly method | Flat-pack bolt-together assembly | |
| Underbed clearance | Open 120mm gap between floor and frame | |
| Color option availability | 1 visible color (pink crushed velvet) | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions (main frame) | 2150 x 1080 x 220 mm | |
|---|---|---|
| Shipping carton dimensions (headboard) | 1200 x 850 x 180 mm | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master or guest bedrooms | |
|---|---|---|
| Target user group | Adult users preferring soft glam, modern romantic bedroom aesthetics | |
| Space saving benefit | Integrated nightstand eliminates need for separate bedside table in compact rooms | |
| Recommended matching decor | Blush, neutral or warm metallic bedroom accessories to complement pink velvet | |
| Recommended mattress type | Memory foam, hybrid or innerspring mattresses 300 mm thick | |
| Recommended placement | Positioned with left shelf accessible from the primary bed entry side | |
| Style compatibility | Works with contemporary, glam, art deco and soft modern interior design schemes |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance (smouldering cigarette test) | |
| EN 13450:2007 | Requirements for wooden slatted bed bases |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structure | |
|---|---|---|
| GB 18584-2001 | Limit of formaldehyde release for wood-based furniture materials | |
| GB/T 19833-2022 | Furniture stability test requirements for bedroom beds |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structure; 2. GB 18584-2001: Limit of formaldehyde release for wood-based furniture materials; 3. GB/T 19833-2022: Furniture stability test requirements for bedroom beds; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
