Product supplierLight Gray Upholstered Wingback Platform Bed with Gold Tapered Legs (Queen Size), CARB P2 grade MDF + plywood composite
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1830 × 2270 × 1470 mm | |
|---|---|---|
| Overall assembled dimensions | 1830 x 2270 x 1470 mm | |
| Floor to top of bed frame (mattress support) | 200 mm | |
| Recommended mattress dimensions | 1830 x 2030 mm | |
| Headboard thickness (wing panel) | 165 mm | |
| Individual headboard cushion size | 800 x 600 x 120 mm | |
| Footboard side rail height | 350 mm | |
| Under-bed clearance height | 130 mm | |
| Gold tapered leg height | 150 mm | |
| Support slat width | 70 mm | |
| Support slat thickness | 18 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static weight capacity (sleepers + mattress) | 363 kg | |
|---|---|---|
| Recommended maximum sleeper weight per person | 120 kg | |
| Bed net weight (assembled) | 82 kg | |
| Fabric upholstery abrasion resistance (reference) | 30000 double rubs | |
| Headboard foam density | 35 kg/m³ | |
| Seam stitch pitch (upholstery) | 8 stitches per inch | |
| Gold leg tube wall thickness | 1.2 mm | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Bed internal frame | CARB P2 grade MDF + plywood composite | |
|---|---|---|
| Headboard upholstery | Matte light gray polyester woven fabric | |
| Headboard cushion fill | High-density polyurethane foam + fiber wrap | |
| Support slats | Solid poplar wood slats mounted on fabric retainer strips | |
| Frame legs | Gold brushed finish tapered carbon steel legs | |
| Side rail and footboard padding | 20mm thick foam backing under upholstery | |
| Connection hardware | Zinc-plated steel bolts, dowels and lock nuts | |
| Matching nightstand frame (optional set) | MDF frame with same gray upholstery + gold legs | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Mattress support system | Wood slat platform with reinforced center support beam | |
|---|---|---|
| Headboard cushion attachment | Removable cushions secured with hidden hook-and-loop fasteners | |
| Under-bed access | 130mm open clearance below frame | |
| Assembly configuration | Knock-down flat pack assembly | |
| Mattress compatibility | Supports memory foam, innerspring, latex and hybrid mattresses | |
| Headboard function | Wingback padded design with two soft back cushions | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Residential master bedrooms | |
|---|---|---|
| Secondary application space | Hotel guest rooms and serviced apartments | |
| Recommended matching furniture | Two matching 2-drawer nightstands, low-profile dresser, upholstered bench | |
| Target user group | Adult consumers seeking modern light luxury bedroom furniture | |
| Style compatibility | Works with contemporary, modern light luxury, minimalist and wabi-sabi interior design schemes | |
| Recommended mattress pairing | 300 mm thick hybrid or memory foam mattress |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture – Beds and mattresses – Safety requirements and test methods | |
|---|---|---|
| EN 1022:2018 | Domestic furniture – Seating – Determination of stability, applicable for bed frame stability |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame strength and stability | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances for wooden furniture, formaldehyde emission limit ≤1.5mg/L | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, applicable for sofa/bed durability |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame strength and stability; 2. GB 18584-2001: Limit of harmful substances for wooden furniture, formaldehyde emission limit ≤1.5mg/L; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, applicable for sofa/bed durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
