Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2040 x 2240 x 1470 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1470 mm | |
| Sleeping surface height from floor | 300 mm | |
| Under-bed clearance | 135 mm | |
| Side rail height | 350 mm | |
| Headboard panel thickness | 120 mm | |
| Side rail thickness | 80 mm | |
| Vertical channel width on headboard | 200 mm | |
| Gold frame trim width | 20 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Recommended mattress thickness | 300 mm | |
| Net weight of bed frame | 75 kg | |
| Slat system static load per slat | 50 kg | |
| Center support leg count | 3 units | |
| Warranty period | 3 years | |
| Available color options | 4 variants | |
| Upholstery abrasion resistance | 50000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard outer frame | Polished gold-plated stainless steel, 1.2mm wall thickness | |
|---|---|---|
| Headboard upholstery | 2.2mm thick top-grain semi-aniline white leather | |
| Headboard padding | 40kg/m³ high-density polyurethane foam, 80mm thick | |
| Inner bed frame | 18mm thick E0-grade engineered plywood with solid wood bracing | |
| Support slats | 14 pieces of polished beech wood, 20mm thick, 70mm wide, 10mm gap between slats | |
| Support legs | Gold-plated metal feet, 50mm diameter, with anti-scratch EVA pads | |
| Hardware connectors | Zinc-plated steel lock bolts and barrel nuts, 8mm diameter | |
| Side rail upholstery | Matching white faux leather over 20mm high-density foam padding | |
| Noise-damping strips | 3mm thick EVA foam strips fixed between slats and frame rails | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Support system | Platform slat design, no box spring required for mattress support | |
|---|---|---|
| Assembly requirement | 2-person assembly with included hex key and hardware kit | |
| Headboard function | Vertical channel padded backrest for seated reading support in bed | |
| Under-bed space | Open clearance for robot vacuum access and low-profile storage items | |
| Frame connection | Locking cam bolt system to eliminate squeaking during regular use | |
| Center support | 3 adjustable metal center legs to reinforce slat system and prevent sag | |
| Surface care | Wipe-clean upholstery surface for routine stain removal with mild detergent | |
| Mattress retention | Recessed platform ledge to prevent mattress sliding during use | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Master bedroom in light luxury, modern or glam residential interiors | |
|---|---|---|
| Target user | Adult couples requiring king-size sleeping space in high-end residential projects | |
| Recommended matching furniture | Gold-trim white nightstands, upholstered bench, and light-toned case goods for coordinated suites | |
| Suitable interior design styles | Modern light luxury, contemporary glam, neoclassical bedroom schemes | |
| Installation requirement | Positioned against a flat wall with minimum 2100mm wall width for proper headboard fit | |
| Use case for hospitality | Suitable for upscale hotel guest rooms and serviced apartment master suites |
EU Market Access Requirements* EN Standards
| EN 747-1:2012+A1:2015 | Domestic bunk beds and high beds safety requirements, applicable to bed structure safety | |
|---|---|---|
| EN 13759:2003 | Furniture test methods for stability of upright cabinets and beds |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for lounge and public seating, not directly applicable; reference for upholstered residential furniture durability |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to inner wood frame inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 16799-2008 | Furniture leather performance and test method, applicable to upholstery inspection | |
| GB/T 19001-2016 | Quality management system reference for production process control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner wood frame inspection; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 3. GB/T 16799-2008: Furniture leather performance and test method, applicable to upholstery inspection; 4. GB/T 19001-2016: Quality management system reference for production process control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
