Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (Queen size) | 2089 x 2266 x 826 mm | |
|---|---|---|
| Mattress opening dimensions | 1524 x 2032 mm | |
| Headboard thickness | 165 mm | |
| Side rail thickness | 61 mm | |
| Footboard height from floor | 381 mm | |
| Floor to slat support height | 305 mm | |
| Integrated upholstered leg height | 152 mm | |
| Slat thickness | 10 mm | |
| Slat width | 64 mm | |
| Slat spacing | 76 mm | |
| Under-bed clearance | 152 mm | |
| Headboard wrap depth at sides | 203 mm | |
| Recommended mattress thickness | 381 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Product net weight | 59 kg | |
| Number of support slats | 12 | |
| Center support leg count | 3 | |
| Fabric abrasion resistance | 50000 double rubs | |
| Foam density (padding) | 32 kg/m³ | |
| Foam rebound rate | 60% | |
| Noise rating during use | 25 dB | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | 100% polyester velvet fabric, terracotta finish | |
|---|---|---|
| Headboard padding | 32 kg/m³ high-density polyurethane foam | |
| Inner structural frame | 18 mm thick plywood and MDF composite | |
| Support slats | Solid hardwood poplar slats | |
| Integrated legs | Fully upholstered wood block legs, rounded edges | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts | |
| Slat mounting strips | EVA foam padded slat caps | |
| Seam construction | Reinforced polyester stitching, 8 stitches per inch | |
| Frame corner joints | Dowel-reinforced glued corner joints | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support | Slatted platform design eliminates need for box spring | |
|---|---|---|
| Noise reduction | EVA foam strips between slats and rails eliminate metal-on-wood squeaks | |
| Leveling adjustment | Plastic adjustable foot pads on each leg compensate for uneven floors | |
| Headboard support | Fixed padded curved headboard provides cushioned back support for sitting in bed | |
| Assembly requirement | Knock-down assembly with included hex key and hardware | |
| Edge protection | Fully rounded upholstered edges on all frame parts prevent impact injuries | |
| Weight distribution | 3 center support legs evenly distribute weight across slat base | |
| Cleaning compatibility | Stain-resistant velvet surface supports spot cleaning with mild detergent | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential main bedroom | Fits Queen size layout for adult master bedrooms with modern organic decor | |
|---|---|---|
| Boutique hotel guest room | Soft curved silhouette and plush upholstery suit high-end accommodation design | |
| Apartment urban dwelling | Low-profile compact footprint works for smaller urban bedroom spaces | |
| Mid-century modern interiors | Warm terracotta color and rounded form complement retro contemporary design schemes | |
| Quiet rest environments | Noise-reduced slat construction supports undisturbed sleep without frame creaking | |
| Child-safe family bedrooms | Fully rounded soft edges eliminate sharp corner impact risks for children |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture - Ignitability resistance to smouldering cigarette |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural safety | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control | |
| GB/T 1952.2-2011 | Technical requirements for upholstered furniture mattresses, applicable to support interface |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural safety; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission control; 3. GB/T 1952.2-2011: Technical requirements for upholstered furniture mattresses, applicable to support interface; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
