Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (W x D x H) | 1860 x 2240 x 1160 mm | |
|---|---|---|
| Headboard height | 1160 mm | |
| Sleeping platform height from floor | 380 mm | |
| Under-bed floor clearance | 305 mm | |
| Recommended mattress thickness | 305 mm | |
| Headboard panel thickness | 120 mm | |
| Side rail height above slat surface | 180 mm | |
| Support slat width | 70 mm | |
| Support slat spacing | 75 mm | |
| Support slat count | 14 | |
| Center support leg count | 5 | |
| Bed leg diameter | 30 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm |
Net weight / load capacity / users / durability
| Total static weight capacity (mattress + users) | 500 kg | |
|---|---|---|
| Recommended maximum user weight per sleeper | 150 kg | |
| Product net weight | 72 kg | |
| Center support static load rating | 250 kg | |
| Single slat static load rating | 40 kg | |
| Upholstery abrasion resistance (Martindale) | 30000 cycles | |
| Frame fastener torque rating | 12 N·m | |
| Recommended warranty period | 2 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Light off-white/light grey matte woven fabric or smooth PU leather | |
|---|---|---|
| Headboard padding | 40mm thick high-resilience polyurethane foam | |
| Internal bed frame | 18mm thick E0-grade engineered plywood and MDF core | |
| Support slats | 15mm thick solid poplar/birch wood slats | |
| Support legs | 1.2mm thick black powder-coated carbon steel, angled tapered design | |
| Central support rail | 1.2mm thick rectangular steel tube | |
| Hardware fasteners | M8 zinc-plated steel bolts, lock washers, and adjustable leveling feet | |
| Side rail upholstery | Matching light-colored fabric/PU with 10mm foam backing | |
| Headboard decorative accent | 8mm wide black faux leather/metal trim strip, vertically centered on headboard | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Support system | Wooden slat platform with steel center rail and support legs, no box spring required | |
|---|---|---|
| Leveling adjustment | 10mm height adjustment on leg feet to compensate for uneven floors | |
| Edge support | Reinforced upholstered side rails to prevent mattress slippage and edge sag | |
| Headboard attachment | Bolt-on fixed headboard aligned to mattress top edge for gap-free fit | |
| Noise dampening | EVA foam gaskets between slats and frame rails to eliminate squeaks during use | |
| Assembly requirement | Two-person assembly with included hex key and hardware, no special tools required | |
| Cleaning compatibility | Spot-cleanable upholstery surface suitable for water-based mild detergent cleaning | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, matched with 2-drawer upholstered nightstands for coordinated modern styling | |
|---|---|---|
| Suitable user group | Adult dual sleepers in urban apartments or modern residential homes, no underbed storage preference | |
| Recommended complementary furniture | Low-pile area rug, wall-mounted pendant lighting, floor-to-ceiling drapery as shown in lifestyle scene | |
| Mattress compatibility note | Pairs with all standard 1800x2000mm foam, latex, hybrid or innerspring mattresses without box spring | |
| Style suitability | Fits contemporary, minimalist, Italian light luxury and modern neutral bedroom design schemes | |
| Space requirement | Minimum room footprint of 3000 x 3300 mm to allow nightstand placement and walking clearance around the bed |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture – Beds and mattresses – Safety requirements and test methods, applicable to structural stability and edge safety | |
|---|---|---|
| EN 1022:2005 | Domestic furniture – Seating – Determination of stability, applicable to frame load and leg stability verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural stability and finish durability | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, required for formaldehyde emission verification | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture beds, applicable to padding, structural safety and performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural stability and finish durability; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, required for formaldehyde emission verification; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture beds, applicable to padding, structural safety and performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
