Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (L x W x H) | 2362 x 2032 x 1016 mm | |
|---|---|---|
| Floor to slat support height | 229 mm | |
| Recommended mattress thickness | 356 mm | |
| Headboard cushion thickness | 152 mm | |
| Side rail width | 203 mm | |
| Footboard height above floor | 356 mm | |
| Under-bed ground clearance | 76 mm | |
| Recessed mattress support area (L x W) | 2032 x 1930 mm | |
| Perimeter rail top thickness | 102 mm | |
| Headboard width (outer edge) | 2032 mm | |
| Slat support spacing | 76 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 449 kg | |
|---|---|---|
| Product net weight | 60 kg | |
| Recommended maximum user weight per sleeper | 150 kg | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Foam padding density (headboard/rails) | 35 kg/m³ | |
| Foam compression set resistance | 10% | |
| Slat system static load rating | 300 kg | |
| Noise performance under normal use | Anti-squeak design | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery covering | Taupe PU faux leather | |
|---|---|---|
| Internal support frame | 18mm thick engineered plywood + MDF panel | |
| Reinforced frame bracing | 1.2mm thick steel tube cross supports | |
| Mattress support slats | 12mm thick solid pine wood slats | |
| Headboard/rail padding | 35kg/m³ high-density polyurethane foam | |
| Base plinth trim | Black matte PVC non-slip base trim | |
| Panel stitching details | 8mm seam pitch reinforced polyester thread | |
| Connection hardware | Zinc-plated steel bolts and barrel nuts | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Fixed wooden slat platform, no box spring required | |
|---|---|---|
| Integrated backrest support | Two fixed padded headboard cushions positioned for two sleepers | |
| Edge retention design | Raised wrap-around perimeter rails | |
| Safety edge design | Fully rounded curved corners on headboard, rails and footboard | |
| Floor protection design | Continuous non-slip plinth base | |
| Assembly requirement | Flat-pack assembly with included hardware and instructions | |
| Upholstery maintenance | Spot clean with damp soft cloth, no harsh solvents | |
| Mattress fit compatibility | Fits standard king size memory foam, latex, innerspring and hybrid mattresses | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms | |
|---|---|---|
| Target user group | Adult couples and individual users seeking modern low-profile bedroom furniture | |
| Recommended interior design styles | Contemporary minimalist, modern luxury, soft curved organic interiors | |
| Use case suitability | Daily residential sleeping use, relaxed sitting upright for reading or screen time in bed | |
| Recommended placement clearance | Minimum 600mm clearance on both sides and foot of bed for easy circulation | |
| Mattress pairing recommendation | Pair with 356 mm thick medium-firm mattress | |
| Floor surface compatibility | Suitable for hardwood, laminate, tile and low-pile carpeted floors |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Applicable safety and strength standard for domestic beds, for static load and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable general technical requirement for wooden furniture, for frame strength and dimensional stability verification | |
|---|---|---|
| GB 18584-2001 | Applicable limit of harmful substances in wooden furniture, for formaldehyde and heavy metal content testing | |
| GB/T 16799-2008 | Applicable standard for polyurethane synthetic leather used in furniture upholstery performance testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable general technical requirement for wooden furniture, for frame strength and dimensional stability verification; 2. GB 18584-2001: Applicable limit of harmful substances in wooden furniture, for formaldehyde and heavy metal content testing; 3. GB/T 16799-2008: Applicable standard for polyurethane synthetic leather used in furniture upholstery performance testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
