Fabric Upholstered Cantilever Visitor Chair with Integrated Armrests (model VC-CAN-001-BLU) is listed under hotel guest room chair, with overall dimensions of 620 × 580 × 800 mm and main material of Imported Ash Solid Wood. Load capacity: 150 kg. Certifications: Cantilever,base,integrated,curved,armrests,upholstered,seat,and,back. This page consolidates 6 groups of specifications, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 620 x 580 x 800 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 9 kg | |
|---|---|---|
| Static load capacity | 150 kg | |
| Stacking capacity | 4 units | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Frame load cycle rating | 100000 cycles | |
| Seat cushion foam density | 40 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | Blue polyester contract fabric | |
|---|---|---|
| Seat padding | High-resilience polyurethane foam | |
| Back padding | Medium-density polyurethane foam | |
| Support frame | Chrome-plated 16mm diameter steel tube | |
| Floor glides | Black non-marking nylon | |
| Internal support shell | Molded plywood inner core |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cantilever flex support | Sled frame provides gentle dynamic flex when seated for comfort | |
|---|---|---|
| Stackable storage | Chairs nest vertically to minimize storage space when not in use | |
| Integrated armrest support | Curved upholstered armrests form continuous wrap with seat and back | |
| Non-marking floor protection | Nylon glides prevent floor scratching on hard or carpeted surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office meeting rooms | Used for short-duration seating around conference tables for internal and guest meetings | |
|---|---|---|
| Reception and waiting areas | Deployed in lobby waiting zones for visitor seating with modern aesthetic |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
