Armless Contoured Red Upholstered Lounge Chair with Chrome Wire Sled Base (model LC-CSL850-RED) is listed under hotel guest room chair, with overall dimensions of 850 × 870 × 970 mm and main material of Imported Ash Solid Wood. Load capacity: 136 kg. Certifications: Modern,design,armless,structure,sled,base,padded,upholstery. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 850 x 870 x 970 mm | |
|---|---|---|
| Seat height | 460 mm | |
| Seat width | 550 mm | |
| Seat depth | 620 mm | |
| Backrest total height | 580 mm | |
| Headrest width | 840 mm | |
| Sled base footprint width | 720 mm | |
| Sled base footprint depth | 820 mm | |
| Steel sled rod diameter | 12 mm | |
| Floor clearance under seat | 220 mm | |
| Side shell thickness at folded edge | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 136 kg | |
|---|---|---|
| Net weight | 25 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam thickness | 120 mm | |
| Backrest foam thickness | 80 mm | |
| Foam rebound rate | 60% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Sled base static load rating | 180 kg | |
| Limited warranty period | 1 year |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back shell upholstery | Top-grain match red leather with visible edge stitching | |
|---|---|---|
| Internal seat frame | 15mm thick molded plywood core with elastic webbing support | |
| Padding material | High-resilience polyurethane foam wrapped in soft polyester batting | |
| Support base | Chrome-plated 12mm diameter solid steel wire sled frame | |
| Base surface finish | Mirror polished triple-layer chrome plating over steel | |
| Floor contact pads | 3mm thick non-marking black rubber pads at each base foot |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating posture support | Fixed contoured ergonomic shell with integrated winged headrest | |
|---|---|---|
| Base stability | Four-point wire sled base distributes weight evenly across floor contact points | |
| Floor protection | Rubber foot pads prevent hard metal contact with hard flooring surfaces | |
| Armrest design | Integrated curved shell side edges without protruding padded armrests |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Lobby and reception spaces | Sculptural design serves as statement seating in office, hotel, or residential entry areas | |
|---|---|---|
| Open lounge and breakout zones | Relaxed fixed recline angle supports casual resting and informal conversation |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
