Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table static load capacity | 80 kg | |
|---|---|---|
| Tabletop distributed serving load | 1.0 kN/m² | |
| Seating capacity | 6 persons | |
| Chair net weight per unit | 7 kg | |
| Recommended pull-out clearance | 700 mm | |
| Seat foam density target | 35 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | Oak-toned wood veneer over 25 mm engineered wood substrate | |
|---|---|---|
| Table frame | Solid rubberwood or equivalent hardwood legs, apron, and curved stretchers with natural finish | |
| Chair frame | Solid hardwood frame with four slender tapered legs and integrated seat rail | |
| Seat upholstery | Tan upholstery over 60 mm padded cushion with rounded front edge | |
| Back upholstery | Tall tan padded back panel attached to the wood outer frame | |
| Fasteners and joinery | Wood-to-wood corner joints with concealed screw or dowel hardware |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating layout | Six independent chairs slide under or away from the table; no armrests interfere with the table edge | |
|---|---|---|
| Support structure | Two paired leg frames connected by front and rear curved floor stretchers resist racking | |
| Floor protection | Plastic or felt glides should be fitted to 32 mm chair legs and table supports to protect hard floors | |
| Storage compatibility | Chairs can be pushed partially beneath the 680 mm-high table opening when not in use |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Suits a compact apartment or home dining area seating six for daily meals and small gatherings | |
|---|---|---|
| Hospitality or staff dining area | Natural wood frame and wipeable tan upholstery fit cafes, canteens, and guest dining rooms |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
