Grey Fabric Wraparound Arm Sled Base Dining Chair (model DC-SLED-GRY-001) is listed under hotel guest room chair, with overall dimensions of 572 × 584 × 838 mm and main material of Imported Ash Solid Wood. Load capacity: 150 kg. Certifications: Modern,minimalist,style,sled,base,frame,upholstered,armchair,cantilever,seating,fixed,non-swivel,structure. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 572 x 584 x 838 mm | |
|---|---|---|
| Seat height | 457 mm | |
| Seat width | 495 mm | |
| Seat depth | 445 mm | |
| Backrest height | 406 mm | |
| Armrest height above floor | 635 mm | |
| Armrest width (per side) | 76 mm | |
| Sled base front-to-back length | 546 mm | |
| Sled base leg tube diameter | 12 mm | |
| Knee clearance under seat | 254 mm | |
| Floor glide diameter | 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Unit net weight | 7 kg | |
| Stacking capacity | 0 units | |
| Fabric Martindale abrasion resistance | 30000 cycles | |
| Seat foam density | 35 kg/m³ | |
| Back foam density | 28 kg/m³ | |
| Foam rebound rate | 45% | |
| Limited warranty period | 1 year | |
| Available color options | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat shell inner frame | 1.2mm thick tubular steel inner frame | |
|---|---|---|
| Seat suspension | S-shaped sinuous steel springs | |
| Padding | Molded polyurethane foam over springs | |
| Upholstery | Grey textured woven polyester fabric | |
| Base frame | Black powder-coated 12mm steel wire sled frame | |
| Floor protection | Injected nylon plastic glides at all base contact points |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Fixed upright position with integrated wraparound arm support | |
|---|---|---|
| Mobility | Non-swivel, slight flex from cantilever sled base | |
| Floor protection | Replaceable plastic glides | |
| Maintenance | Spot-cleanable fabric upholstery |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining space | Matches modern dining tables 760 mm height for home dining rooms | |
|---|---|---|
| Commercial cafe seating | Durable steel frame suitable for light-traffic restaurant and cafe use |
EU Market Access Requirements* EN Standards
| Furniture seating strength | EN 12520:2015 | |
|---|---|---|
| Contract seating stability | EN 16139:2013 | |
| Upholstered furniture fire resistance | EN 1021:2014 |
US and Canada office-furniture standards
| Chair general purpose test | ANSI/BIFMA X5.1:2017 | |
|---|---|---|
| Chair static load test | ANSI/BIFMA X5.1 Clause 5 | |
| Chair durability test | ANSI/BIFMA X5.1 Clause 11 |
Standards applicable to China-market projects
| Chair structural strength | GB/T 3324 | |
|---|---|---|
| Upholstered furniture safety | GB 28007 | |
| Furniture mechanical performance | GB/T 10357.3 |
This product must meet the following technical requirements: 1. Chair structural strength: GB/T 3324; 2. Upholstered furniture safety: GB 28007; 3. Furniture mechanical performance: GB/T 10357.3; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
