Mid-Century Solid Wood Dining Armchair with Woven Cord Seat (model DC-CW-580N) is listed under hotel guest room chair, with overall dimensions of 580 × 546 × 873 mm and main material of Imported Ash Solid Wood. Load capacity: 300 kg. Certifications: Minimalist,style,stationary,open-frame,construction,integrated,curved,armrest-back. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 580 x 546 x 873 mm | |
|---|---|---|
| Seat height | 470 mm | |
| Seat width | 470 mm | |
| Seat depth | 495 mm | |
| Backrest height above seat | 330 mm | |
| Armrest height above floor | 648 mm | |
| Front leg diameter | 32 mm | |
| Rear leg cross-section | 35 x 25 mm | |
| Lower stretcher height above floor | 180 mm | |
| Armrest projection from back | 120 mm | |
| Seat frame rail thickness | 25 mm | |
| Floor clearance under stretcher | 170 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Maximum static user weight capacity | 225 kg | |
|---|---|---|
| Net product weight | 7.5 kg | |
| Seat surface breathability | 100% air-permeable open weave | |
| Frame structural static load on stretcher | 300 kg | |
| Cord seat sag resistance service life | 10 years | |
| Seam pitch on cord weave | 8 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Frame construction | Solid light natural hardwood with clear matte finish | |
|---|---|---|
| Seat surface | Double-woven natural paper cord in grid pattern | |
| Joinery | Mortise-and-tenon, dowel and screwed reinforced joints | |
| Foot protection | Non-marking polymer floor glides fitted to leg ends | |
| Frame finish | Low-VOC natural oil or clear lacquer coating | |
| Cross stretcher material | Solid hardwood matching frame tone and species |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Stationary fixed-position dining seating | |
|---|---|---|
| Structural bracing | Angled X-style cross stretchers between legs | |
| Floor protection | Smooth fixed glides on all four leg ends | |
| Back and arm support | Continuous curved wood component forms integrated backrest and armrests |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining areas | Pairs with 750 mm height standard dining tables for casual or formal meals | |
|---|---|---|
| Cafe and casual restaurant seating | Compact footprint and durable construction suit high-turnover food service spaces |
EU Market Access Requirements* EN Standards
| EN 16139:2013 Level 1 | Furniture: Strength, durability and safety for non-domestic seating, recommended for contract use verification |
|---|
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2022 | Standard for lounge and public seating, applies to static load and durability testing validation |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame strength and finish quality checks | |
|---|---|---|
| GB/T 10357.3-2013 | Furniture mechanical test for chair strength and durability, recommended for production quality acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame strength and finish quality checks; 2. GB/T 10357.3-2013: Furniture mechanical test for chair strength and durability, recommended for production quality acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
