Contemporary Armless Swivel Lounge Chair, Navy Upholstery with Chrome Disc Base (model L-CHR-SW-001-NAV) is listed under hotel guest room chair, with overall dimensions of 851 × 851 × 820 mm and main material of Imported Ash Solid Wood. Certifications: contemporary,style,armless,swivel,structure,upholstered,soft,seating,metal,disc,base. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 851 x 851 x 820 mm | |
|---|---|---|
| seat height | 457 mm | |
| seat width | 660 mm | |
| seat depth | 584 mm | |
| backrest height above seat | 290 mm | |
| backrest width | 610 mm | |
| central support stem diameter | 50 mm | |
| round disc base diameter | 584 mm | |
| disc base thickness | 10 mm | |
| seat cushion thickness | 100 mm | |
| backrest cushion thickness | 80 mm | |
| floor clearance under base | 5 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net weight | 39 kg | |
|---|---|---|
| static weight capacity | 136 kg | |
| seat foam density | 40 kg/m³ | |
| foam rebound rate | 60% | |
| upholstery abrasion resistance | 50000 double rubs | |
| swivel rotation range | 360 degrees | |
| seam stitch pitch | 8 stitches per 30 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| seat and back upholstery | Dark navy textured woven polyester fabric | |
|---|---|---|
| cushion core | High-density polyurethane foam wrapped in soft polyester fiber | |
| internal support frame | 25 mm thick kiln-dried hardwood frame | |
| central support stem | Polished chrome-plated 2mm thick steel tube | |
| floor base | Polished chrome-plated 10mm thick flat steel disc | |
| swivel bearing assembly | Hardened steel precision swivel bearing |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| swivel mechanism | 360-degree full rotation via central precision bearing between stem and base | |
|---|---|---|
| seating posture | Upright relaxed lounge posture with curved lumbar support from oval back | |
| floor protection | Smooth flat disc base with no sharp edges to prevent floor scratching | |
| base stability | Wide weighted disc base prevents tipping during normal swivel and seating use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| lounge area seating | Suitable for modern office breakout zones, hotel lobbies, and residential living rooms | |
|---|---|---|
| accent seating placement | Works as standalone accent chair next to side tables or in grouped lounge configurations |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
