Modern Contoured Upholstered Dining Armchair with Semicircular Back Cutout and Black Tapered Metal Legs (model DIN-ARM-CUT-001) is listed under hotel guest room chair, with overall dimensions of 600 × 620 × 850 mm and main material of Imported Ash Solid Wood. Load capacity: 159 kg. Certifications: Modern,design,fixed,four-leg,base,integrated,armrests,open,back,cutout. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 600 x 620 x 850 mm | |
|---|---|---|
| Seat height | 510 mm | |
| Seat width | 480 mm | |
| Seat depth | 460 mm | |
| Backrest height from seat | 390 mm | |
| Armrest height from floor | 660 mm | |
| Armrest width | 60 mm | |
| Leg diameter at floor contact | 20 mm | |
| Leg spread (outer front to rear) | 560 mm | |
| Semicircular back cutout width | 280 mm | |
| Floor clearance under seat | 270 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 159 kg | |
|---|---|---|
| Net weight per chair | 8.5 kg | |
| Cushion foam density | 40 kg/m³ | |
| Cushion foam thickness | 60 mm | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Leg static load rating per leg | 45 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back shell | Molded engineered wood inner frame | |
|---|---|---|
| Upholstery material | PU microfiber leather / woven fabric options | |
| Leg material | 1.2mm thick matte black carbon steel | |
| Seat padding | High-resilience polyurethane foam | |
| Foot pads | Anti-scratch non-slip PP plastic | |
| Connection hardware | Zinc-plated steel screws and mounting plates |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Base structure | Fixed four-leg non-swivel base | |
|---|---|---|
| Assembly requirement | Knock-down leg attachment only | |
| Back cutout function | Semicircular open cutout between seat and back | |
| Armrest function | Integrated flared armrests |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Pairs with standard 750mm high dining tables for 6seat configurations | |
|---|---|---|
| Cafe and bistro seating | Stackable-compact footprint suits small commercial dining spaces |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating - Mechanical safety requirements | |
|---|---|---|
| EN 1022:2018 | Domestic seating - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 24821-2009 | Furniture hardware strength and durability requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 24821-2009: Furniture hardware strength and durability requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
