Armless Swivel Lounge Side Chair with Olive Green Upholstered Cushions (model ZY-08) is listed under hotel guest room chair, with overall dimensions of 880 × 910 × 1100 mm and main material of Imported Ash Solid Wood. Load capacity: 204 kg. Certifications: armless,design,swivel,lounge,structure,4-star,glide,base,fabric,upholstery,molded,plastic,shell. This page consolidates 6 groups of specifications and ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 880 x 910 x 1100 mm | |
|---|---|---|
| Seat height | 430 mm | |
| Seat width | 550 mm | |
| Seat depth | 560 mm | |
| Backrest height above seat | 520 mm | |
| 4-star base diameter | 720 mm | |
| Central column diameter | 50 mm | |
| Floor glide footprint diameter | 20 mm | |
| Seat cushion thickness | 80 mm | |
| Back cushion thickness | 60 mm | |
| Backrest angle from vertical | 12 degrees | |
| Minimum knee clearance under seat front | 200 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 25 kg | |
|---|---|---|
| Recommended static load capacity | 204 kg | |
| Seat foam density | 60 kg/m³ | |
| Fabric abrasion resistance | 100000 double rubs | |
| Seat foam rebound rate | 60% | |
| Swivel rotation range | 360 degrees | |
| Seam stitch pitch | 8 mm | |
| Recommended daily usage duration | 8 hours | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer seat shell | Molded white polypropylene with smooth matte finish | |
|---|---|---|
| Upholstery fabric | Woven olive green polyester fabric with textured surface | |
| Cushion core | High-resilience molded polyurethane foam | |
| 4-star swivel base | 1.8mm thick white powder-coated steel with welded joints | |
| Floor glides | Injection-molded black non-marking nylon with anti-slip pad | |
| Central support column | Powder-coated steel gas lift cylinder with height adjustment actuator |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel mechanism | Smooth rotating movement via central sealed bearing stem | |
|---|---|---|
| Fixed floor stability | Four contact-point glides prevent movement during seated use | |
| Segmented lumbar support | Contoured separate lower back cushion aligns with natural spine curve | |
| Low-maintenance surface design | Smooth plastic shell allows wipe-cleaning; fabric cushions resist light staining |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception and waiting areas | Modern armless profile supports short-to-medium term visitor seating in professional spaces | |
|---|---|---|
| Collaborative breakout zones | Swivel function supports casual conversation and flexible team interaction in open workspaces |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.1 (2017) | General-purpose office seating safety and performance standard, recommended for commercial procurement | |
|---|---|---|
| ANSI/BIFMA e3 Furniture Sustainability Standard | Sustainability certification reference for low-VOC, environmentally responsible material selection |
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
