Cognac Upholstered Height-Adjustable 4-Star Swivel Lounge Office Armchair (model SWL-4S-CGN-ADJ) is listed under hotel guest room chair, with overall dimensions of 760 × 660 × 880 mm and main material of Imported Ash Solid Wood. Load capacity: 204 kg. Certifications: modern,minimalist,style,integrated,wrap-around,armrests,caster-free,fixed,base,gas,lift,height,adjustment,360-degree,swivel. This page consolidates 6 groups of specifications, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 760 x 660 x 880 mm | |
|---|---|---|
| Seat width | 660 mm | |
| Seat depth | 560 mm | |
| Maximum seat height | 540 mm | |
| Minimum seat height | 440 mm | |
| Backrest height | 320 mm | |
| Backrest width | 680 mm | |
| Armrest height above seat | 180 mm | |
| 4-star base span diameter | 600 mm | |
| Gas lift cylinder diameter | 50 mm | |
| Gas lift adjustment stroke | 100 mm | |
| Armrest width | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net chair weight | 28 kg | |
|---|---|---|
| Maximum static load capacity | 204 kg | |
| Seat foam density | 25 kg/m³ | |
| Seat foam thickness | 80 mm | |
| Backrest foam thickness | 60 mm | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Swivel rotation range | 360 degrees | |
| Seam stitch pitch | 8 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back shell | Plywood core wrapped in high-density polyurethane foam | |
|---|---|---|
| Upholstery | 1.2mm thick cognac brown PU faux leather with matte finish | |
| Internal support frame | 1.5mm thick welded steel seat support structure | |
| Gas lift cylinder | Chrome-plated steel Class 3 pneumatic lift | |
| 4-star base | 2mm thick brushed polished die-cast aluminum flat spokes | |
| Height adjustment lever | Black powder-coated steel actuating lever |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Pneumatic lever actuates 100mm gas lift travel to adjust seat height | |
|---|---|---|
| Swivel function | 360-degree smooth rotation around central column via sealed bearing | |
| Static use design | Caster-free fixed base for stable stationary placement in lounge or meeting areas | |
| Integrated arm support | Continuous wrap-around padded armrests provide forearm support during seated use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office guest seating | Placed in front of executive desks for short-stay visitor seating | |
|---|---|---|
| Open collaboration lounge areas | Used in breakout zones for informal meetings or individual relaxation |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
