Walnut Finish Spindle Back Armless Dining Side Chair with Dark Upholstered Seat (model DC-SB5-WL-PU01) is listed under hotel guest room chair, with overall dimensions of 559 × 630 × 965 mm and main material of Imported Ash Solid Wood. Load capacity: 300 kg. Certifications: modern,style,fixed,four-leg,structure,armless,spindle,back,upholstered,padded,seat. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 559 x 630 x 965 mm | |
|---|---|---|
| seat height | 498 mm | |
| seat width | 520 mm | |
| seat depth | 495 mm | |
| seat cushion thickness | 60 mm | |
| backrest total height | 467 mm | |
| backrest spindle count | 5 units | |
| front leg diameter at floor | 32 mm | |
| rear leg diameter at floor | 28 mm | |
| seat frame rail thickness | 30 mm | |
| floor to front apron clearance | 248 mm | |
| spindle diameter | 18 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net weight per chair | 12 kg | |
|---|---|---|
| static weight capacity | 150 kg | |
| recommended user weight | 110 kg | |
| frame joint static load rating | 300 kg | |
| seat foam density | 45 kg/m³ | |
| foam rebound rate | 45% | |
| upholstery abrasion resistance | 50000 double rubs | |
| warranty period | 90 days | |
| available color options | 3 finishes | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| chair frame | Walnut-stained solid rubberwood with smooth satin lacquer finish | |
|---|---|---|
| seat support base | 12 mm thick laminated veneer lumber panel | |
| seat upholstery | 1.0 mm thick dark brown PU (faux leather) with wipe-clean surface | |
| seat cushion fill | 45 kg/m³ high-density polyurethane foam | |
| floor glides | Injection-molded felt-padded nylon foot caps | |
| backrest components | Solid wood curved top rail, vertical spindles, and integrated rear posts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| back support | Fixed 4-degree reclined spindle back with no tilt or adjustment mechanism | |
|---|---|---|
| floor protection | Non-marking felt glides to prevent hard floor scratching, no adjustable foot pads | |
| structural stability | Cross-braced seat apron and mortise-and-tenon leg joints for wobble-free use | |
| seating posture | Armless design to allow tucking fully under standard 750mm height dining tables |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| single carton dimensions | 820 x 550 x 300 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential dining spaces | Suitable for home dining rooms paired with 750mm standard height dining tables | |
|---|---|---|
| cafe and casual restaurant use | Appropriate for light commercial bistro and cafe seating with wipe-clean PU surface |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture strength, durability and safety for seating, applicable for structural testing | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture ignitability resistance (cigarette test), applicable for seat upholstery |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame strength and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame strength and finish quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
