Two-Tone Upholstered Wire Sled Base Lounge Armchair (model LS-WB-780) is listed under hotel guest room chair, with overall dimensions of 780 × 710 × 780 mm and main material of Imported Ash Solid Wood. Load capacity: 160 kg. Certifications: Modern,minimalist,style,fixed,sled,base,integrated,wrap-around,armrests,two-tone,upholstery. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 780 x 710 x 780 mm | |
|---|---|---|
| Seat height | 410 mm | |
| Seat width | 580 mm | |
| Seat depth | 520 mm | |
| Seat cushion thickness | 100 mm | |
| Backrest height | 420 mm | |
| Armrest height above seat | 190 mm | |
| Armrest width | 80 mm | |
| Wire base footprint width | 660 mm | |
| Wire base footprint depth | 620 mm | |
| Under-seat clearance | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight per unit | 18 kg | |
|---|---|---|
| Recommended static load capacity | 160 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 40% | |
| Back foam density | 35 kg/m³ | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30 mm | |
| Base static load rating | 300 kg | |
| Warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat support frame | 1.8 mm thick welded steel tube inner frame with S-shape suspension springs | |
|---|---|---|
| Seat cushion padding | High-resilience polyurethane foam wrapped with 20 gsm polyester fiber batting | |
| Backrest padding | CMHR flame-retardant molded polyurethane foam | |
| Upholstery fabric | Woven contract-grade polyester/wool blend fabric, 0.8 mm thickness, breathable matte finish | |
| Support base | 8 mm diameter white powder-coated solid steel wire sled frame, welded joints | |
| Floor protection | 10 mm thick non-marking polyethylene glides fitted to wire base feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating function | Fixed non-reclining relaxed lounge seating position with integrated wrap-around arm support | |
|---|---|---|
| Base stability | Continuous wire sled frame provides 4-point floor contact with no tipping risk under normal use | |
| Upholstery performance | Tight tailored upholstery over molded foam shell retains shape with regular daily use | |
| Maintenance feature | Smooth tight-weave upholstery allows spot cleaning with mild upholstery detergent |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception and waiting areas | Compact footprint and casual design suits visitor waiting space seating groups | |
|---|---|---|
| Open office breakout zones | Relaxed seating angle supports informal collaboration and short rest breaks |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Furniture seating stability test standard for domestic and contract seating | |
|---|---|---|
| EN 16139:2013 | Strength, durability and safety requirements for non-domestic seating | |
| EN 13759:2012 | Upholstered furniture ignition resistance test for cigarette and match sources |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Standard for lounge seating durability, strength and stability for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | General office furniture safety reference for structural load requirements | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for low-emission material selection guidance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for inner shell structural integrity checks | |
|---|---|---|
| GB 20286-2006 | Flame retardant requirements for public venue furniture upholstery and foam components | |
| GB/T 10357.3-2013 | Test method for seat and back durability of furniture, applicable for strength verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for inner shell structural integrity checks; 2. GB 20286-2006: Flame retardant requirements for public venue furniture upholstery and foam components; 3. GB/T 10357.3-2013: Test method for seat and back durability of furniture, applicable for strength verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
