Armless Red Fabric Swivel Lounge Chair with 4-Prong Chrome Star Base (model LC-RD-SW-4PRONG-01) is listed under hotel guest room chair, with overall dimensions of 760 × 760 × 965 mm and main material of Imported Ash Solid Wood. Load capacity: 136 kg. Certifications: armless,design,swivel,pedestal,base,curved,monocoque,shell,pointed,wing,back,chrome-finished,metal,frame. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 760 x 760 x 965 mm | |
|---|---|---|
| Seat width | 610 mm | |
| Seat depth | 520 mm | |
| Seat height | 445 mm | |
| Backrest height | 520 mm | |
| 4-prong base span | 670 mm | |
| Central pedestal stem diameter | 50 mm | |
| Pedestal stem height | 320 mm | |
| Floor glide pad size | 25 mm square | |
| Seat shell thickness at front edge | 80 mm | |
| Backrest tip projection above seat | 520 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 136 kg | |
|---|---|---|
| Assembled net weight | 22 kg | |
| Upholstery fabric abrasion resistance | 30000 double rubs | |
| Seat foam density | 40 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Seam stitch pitch | 3 stitches per cm | |
| Swivel rotation range | 360 degrees | |
| Backrest fixed recline angle | 15 degrees backward | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back upholstery | 1.2 mm thick bright red woven polyester fabric | |
|---|---|---|
| Internal seat support shell | 12 mm thick molded plywood frame | |
| Seat and back padding | 76 mm thick high-density polyurethane foam | |
| Pedestal stem and star base | 2 mm thick polished chrome-plated steel | |
| Floor protection glides | Non-marking black rubber pads | |
| Swivel mechanism | Steel ball-bearing swivel joint at stem-shell junction |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| 360-degree swivel rotation | Smooth ball-bearing rotation without tilt or height adjustment | |
|---|---|---|
| Fixed ergonomic recline | Permanent 15-degree backward back angle optimized for relaxed lounging | |
| Floor protection | Non-scuff rubber glides on all four base prongs for hard surface use | |
| Enveloping winged back support | Curved upward-pointing back tips provide lateral upper back support |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Lobby and reception spaces | Bold red design creates a focal point in waiting areas and modern office lobbies | |
|---|---|---|
| Residential living rooms | Compact swivel footprint works well in open-plan lounge spaces and reading nooks |
EU Market Access Requirements* EN Standards
| Seating stability recommendation | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture flammability recommendation | EN 1021:2014 |
US and Canada office-furniture standards
| Lounge seating durability recommendation | ANSI/BIFMA X2022 |
|---|
Standards applicable to China-market projects
| Upholstered furniture safety recommendation | GB 28007 | |
|---|---|---|
| Furniture structural safety recommendation | GB/T 3324 |
This product must meet the following technical requirements: 1. Upholstered furniture safety recommendation: GB 28007; 2. Furniture structural safety recommendation: GB/T 3324; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
