Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1300 x 700 x 460 mm | |
|---|---|---|
| tabletop thickness | 30 mm | |
| leg height | 120 mm | |
| drawer face height | 120 mm | |
| lower shelf height above floor | 120 mm | |
| drawer internal depth | 380 mm | |
| lower shelf usable depth | 620 mm | |
| leg cross-section size | 40 x 40 mm | |
| floor clearance under lower shelf | 80 mm | |
| drawer front width per unit | 580 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| tabletop distributed static load | 50 kg | |
|---|---|---|
| single drawer static load | 10 kg | |
| lower shelf distributed static load | 25 kg | |
| product net weight | 30 kg | |
| finish abrasion resistance cycles | 2000 cycles | |
| corner static load resistance | 15 kg | |
| warranty period | 12 months | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop substrate | 18 mm thick MDF core | |
|---|---|---|
| tabletop finish | Open-pore walnut wood veneer with water-based lacquer | |
| support frame and drawer trim | 1.2 mm thick gold-toned brushed metal tube | |
| lower display shelf | 8 mm thick clear tempered glass | |
| drawer boxes | 15 mm thick engineered wood with fabric-lined interior | |
| drawer slides | 3-section ball-bearing full-extension slides | |
| support legs | Square metal legs with integrated non-slip adjustable foot pads | |
| drawer pulls | Polished gold metal cylindrical pulls | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| drawer storage access | Two equal-width front drawers pull fully forward to access enclosed storage for remotes, coasters and small items | |
|---|---|---|
| open shelf display | Mid-level open glass shelf provides visible storage for books, decor and frequently used living room items | |
| floor leveling adjustment | Adjustable foot pads on each leg compensate for 10 mm of uneven floor height to prevent wobble | |
| surface cleaning compatibility | Stain-resistant lacquer finish supports wiping with mild household cleaners without finish damage | |
| drawer soft-close function | Integrated damping mechanism closes drawers silently without slamming after gentle push | |
| stable anti-tip design | Four-point leg placement and low center of gravity prevent tipping when uneven loads are placed on edges | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 1400 x 800 x 200 mm | |
|---|---|---|
| shipping gross weight | 35 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| residential living room placement | Positioned centrally in front of three-seat sofas in apartment or villa living rooms for drink and decor placement | |
|---|---|---|
| lounge area application | Suitable for hotel lobby or executive lounge seating areas to serve guest refreshments and decorative display | |
| matched furniture configuration | Pairs with 2.4 m three-seat sofas and matching armchairs for a coordinated light luxury seating set | |
| user group suitability | Ideal for residential homeowners, hotel procurement and commercial interior design projects requiring elegant storage coffee tables | |
| space size requirement | Requires minimum 2.4 m wide seating area to leave 500 mm clearance around the table for movement | |
| maintenance consideration | Suitable for low-maintenance environments where enclosed storage reduces visible clutter in public or private spaces |
EU Market Access Requirements* EN Standards
| furniture stability standard | EN 12521:2015 | |
|---|---|---|
| surface durability | EN 15187:2006 | |
| glass safety requirement | EN 12150:2015 |
Standards applicable to China-market projects
| general technical requirement | GB/T 3324 | |
|---|---|---|
| surface coating limit | GB 18584 | |
| tempered glass safety | GB 15763.2 |
This product must meet the following technical requirements: 1. general technical requirement: GB/T 3324; 2. surface coating limit: GB 18584; 3. tempered glass safety: GB 15763.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
