Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 800 x 480 mm | |
|---|---|---|
| Tabletop thickness | 45 mm | |
| Central drawer internal dimensions | 700 x 350 x 130 mm | |
| Lower open shelf clearance height | 220 mm | |
| Leg section size | 60 x 60 mm | |
| Leg wall thickness | 30 mm | |
| Metallic trim width | 15 mm | |
| Open shelf usable depth | 720 mm | |
| Corner radius | 5 mm | |
| Floor to lower shelf height | 120 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load | 91 kg | |
|---|---|---|
| Drawer static load capacity | 15 kg | |
| Product net weight | 46 kg | |
| Lower shelf distributed load | 30 kg | |
| Corner static load without deformation | 15 kg | |
| Adjustable foot pad height adjustment | 10 mm | |
| Surface abrasion resistance cycles | 1000 cycles | |
| Warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Solid ash wood with dark walnut open-grain finish | |
|---|---|---|
| Frame and leg material | Solid rubberwood with reinforcing internal battens | |
| Surface coating | Water-based open wood finish | |
| Drawer front decorative trim | Brushed gold-toned zinc alloy accent strip | |
| Drawer slides | Cold-rolled steel soft-close full-extension guides | |
| Adjustable foot pads | Nylon non-slip adjustable floor pads | |
| Drawer panel | 18 mm thick solid wood veneered MDF core panel | |
| Lower shelf panel | 25 mm thick solid wood laminated panel | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central drawer operation | Soft-close full-extension drawer with two decorative pull handles, extends 350 mm | |
|---|---|---|
| Open shelf storage | Fixed lower open shelf for display and frequently used items | |
| Level adjustment | Four adjustable non-slip foot pads to compensate for uneven floors | |
| Surface protection | Stain-resistant open finish allows easy wiping of spills without surface damage | |
| Structural stability | Reinforced leg-to-frame connection prevents wobble under normal household loads | |
| Storage zoning | Combines closed concealed drawer storage and open display storage for flexible use | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room placement | Positioned centrally in front of 3-seat sofas for tea service and decor display | |
|---|---|---|
| Reception area use | Suitable for formal office reception lounge areas for guest refreshment service | |
| Villa lounge application | Ideal for high-end residential villa or club lounge seating groups | |
| Storage function | Supports storage of remote controls, coasters and small living room accessories | |
| Color coordination | Dark walnut finish coordinates with light neutral upholstery and warm wood interiors | |
| Residential use suitability | Designed for daily household use in family living rooms with standard traffic levels |
EU Market Access Requirements* EN Standards
| Safety requirement | EN 12521:2015 Furniture - Strength, durability and safety - Requirements for domestic tables | |
|---|---|---|
| Surface emission | EN 13986:2004 Wood-based panels for use in construction - Characteristics, evaluation of conformity |
Standards applicable to China-market projects
| General technical requirement | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Surface coating limit | GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| Stability test | GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables |
This product must meet the following technical requirements: 1. General technical requirement: GB/T 3324General technical requirements for wooden furniture; 2. Surface coating limit: GB 18584Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 3. Stability test: GB/T 10357.1Test of mechanical properties of furniture - Strength and durability of tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
