2-Person Face-to-Face Office Workstation Desk with Central Divider and Integrated End Storage Cabinet (model WS-2F-WAL-1400) is listed under Open Workstation, with overall dimensions of 1400 × 1200 × 750 mm and main material of Particle‑board (PB). Load capacity: 127 kg. Certifications: Modern,open-plan,style,2-person,layout,integrated,storage,metal,frame,desktop,privacy,screen. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall assembled dimensions | 1400 x 1200 x 750 mm | |
|---|---|---|
| desktop thickness | 25 mm | |
| privacy divider height above desktop | 350 mm | |
| privacy divider thickness | 35 mm | |
| per-user worksurface depth | 600 mm | |
| knee clearance height under desktop | 730 mm | |
| knee clearance depth under desktop | 450 mm | |
| integrated end storage cabinet dimensions | 400 x 600 x 680 mm | |
| tubular metal leg diameter | 50 mm | |
| cable grommet diameter | 60 mm | |
| edge band thickness | 2 mm | |
| metal frame tube wall thickness | 1.5 mm | |
| adjustable leveling foot adjustment range | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| static desktop load capacity per user side | 127 kg | |
|---|---|---|
| product net weight | 85 kg | |
| drawer slide durability | 50000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| recommended user capacity | 2 people | |
| commercial warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop surface | E1 grade particleboard core with walnut wood-grain thermally fused laminate | |
|---|---|---|
| support legs | Powder-coated matte black round steel tubing | |
| privacy divider | Light grey fabric-faced acoustic panel with metal edge frame | |
| storage cabinet carcass | E1 grade MDF with dark grey and walnut melamine finish | |
| edge trim | 2mm thick impact-resistant PVC edge banding | |
| hardware and feet | Zinc-plated steel hardware with nylon adjustable leveling feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| cable management | Center-positioned desktop cable grommet with under-desk cable routing space | |
|---|---|---|
| storage access | Integrated fixed end cabinet with pull-out storage compartment for office supplies | |
| modular connectivity | Pre-drilled connection points for linking adjacent workstations | |
| floor leveling | Adjustable feet on all support points to compensate for uneven flooring |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| open plan office work areas | Ideal for team-based open offices, providing separated workspaces for adjacent staff | |
|---|---|---|
| small business and startup offices | Space-efficient 2-person layout for compact office floor plans |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2010 | Office worktables safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic and safety reference for seated workstation design | |
| EN 1022:2018 | Domestic and commercial furniture seating stability reference for leg clearance design |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products durability and safety standard for commercial office workstation load testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for integrated cabinet and drawer components | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and cabinet components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and leg components | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood-based furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and cabinet components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and leg components; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood-based furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
