Automatic mm / inch conversion · Core engineering specifications
| overall cluster dimensions | 2800 x 1200 x 750 mm | |
|---|---|---|
| individual workstation workspace per user | 1400 x 600 mm | |
| desktop thickness | 25 mm | |
| privacy divider height above desktop | 305 mm | |
| knee clearance height under desktop | 650 mm | |
| knee clearance depth per user position | 550 mm | |
| integrated CPU compartment internal width | 220 mm | |
| PVC/ABS edge banding thickness | 2 mm | |
| steel leg tube wall thickness | 1.5 mm | |
| desktop cable grommet diameter | 80 mm | |
| drawer internal usable depth | 450 mm | |
| base leveling foot adjustment range | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| total cluster net weight | 260 kg | |
|---|---|---|
| desktop uniform static load capacity | 100 kg per workstation position | |
| surface abrasion resistance | 2000 cycles | |
| fabric panel acoustic noise reduction | 15 dB | |
| applicable number of users | 4 | |
| drawer slide cycle rating | 50000 open/close cycles | |
| hinge cycle rating for cabinet doors | 80000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | E1 grade melamine-faced MDF with anti-scratch matte finish | |
|---|---|---|
| edge protection | 2mm thick PVC edge banding with rounded impact-resistant profile | |
| support frame and legs | Powder-coated white steel tube angled outer legs with adjustable leveling feet | |
| privacy divider construction | Sage green tackable polyester fabric over 25mm foam-padded MDF core with steel inner frame | |
| lower storage cabinet body | White melamine-faced engineered wood panel cabinetry with light wood grain fluted front trim | |
| cabinet hardware | Zinc alloy drawer pulls, steel ball-bearing drawer slides, concealed cabinet hinges | |
| cable management components | ABS plastic cable grommets, powder-coated steel under-desk cable tray | |
| storage drawer interior | Melamine-lined engineered wood drawer boxes with smooth anti-snag interior finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| desktop privacy partition | Central fabric divider blocks direct line of sight between opposing seated users to reduce distraction | |
|---|---|---|
| integrated CPU storage | Open under-desk compartments sized to hold full-size desktop towers to free up desktop space | |
| lockable drawer storage | Individual lockable drawers for each user secure personal office supplies and documents | |
| cable management system | Desktop grommets route power and data cables to under-desk cable tray to eliminate surface clutter | |
| leveling adjustment | Threaded base feet adjust to compensate for uneven carpet or hard flooring for stable desktop placement | |
| modular assembly | Bracket-connected panel and frame construction allows disassembly for office reconfiguration or relocation | |
| built-in power access | Desktop integrated power outlets provide convenient connection for laptops, lamps and mobile devices | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office staff areas | Fits 4 employees in small floor footprint for high-density team work zones | |
|---|---|---|
| small startup office spaces | All-in-one cluster includes storage and cable management to reduce additional furniture purchases | |
| call center and administrative departments | Short dividers reduce visual distraction while maintaining supervisor line of sight | |
| corporate department expansion zones | Modular construction matches standard panel office systems for easy fleet expansion | |
| co-working shared workspaces | Fixed individual storage and dedicated power points suit rotating daily desk users |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables safety, strength and durability testing methods, applicable for quality verification | |
| EN 13722:2004 | Office furniture storage units performance requirements, applicable to integrated cabinets |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for strength, durability and functional performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk structural performance | |
|---|---|---|
| GB/T 3327-2016 | Performance standards for office desks and tables, applicable to load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel substrates | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable to desk panel materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk structural performance; 2. GB/T 3327-2016: Performance standards for office desks and tables, applicable to load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade panel substrates; 4. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable to desk panel materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
