Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Knee clearance height under desktop | 680 mm | |
| Knee clearance width between frame and pedestal | 850 mm | |
| Right storage pedestal dimensions | 450 x 600 x 700 mm | |
| ABS edge banding thickness | 2 mm | |
| Steel O-leg frame section width | 40 mm | |
| Cable grommet diameter | 55 mm | |
| Leveling foot adjustment height | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop even static load capacity | 150 kg | |
|---|---|---|
| Recommended user weight capacity | 136 kg | |
| Unit net weight | 80 kg | |
| Surface wear resistance cycles | 2000 | |
| Drawer slide open/close cycle rating | 50000 cycles | |
| Lock cycle rating | 10000 cycles | |
| Warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E0-grade particleboard | |
|---|---|---|
| Desktop finish | Matte white melamine laminate | |
| Edge treatment | 2mm thick white ABS edge banding | |
| Support frame | Powder-coated carbon steel O-leg | |
| Storage pedestal body | 18mm thick white melamine faced particleboard | |
| Drawer slides | Cold-rolled steel ball-bearing slides | |
| Locks | Zinc alloy keyed cam locks | |
| Leveling feet | Nylon base with steel threaded stem | |
| Cable grommet | ABS plastic with brush insert | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Keyed storage locking | Single key operates upper drawer and lower cabinet | |
|---|---|---|
| Cable management | Desktop grommet routes power and data cables from work surface to floor | |
| Floor leveling | Rotating adjustable feet compensate for uneven floor surfaces | |
| Cantilever leg access | Open O-frame left leg creates unobstructed knee space | |
| Storage organization | Shallow upper drawer for stationery, deep lower cabinet for file storage | |
| Surface resistance | Melamine finish resists coffee stains, pen marks and minor scratches | |
| Chair clearance | 700mm minimum knee space depth fits standard ergonomic office chairs | |
| Assembly hardware | Steel-to-steel fixing bolts connect frame to desktop and pedestal | |
| Lockable upper drawer internal dimensions | 400 x 500 x 120 mm | |
| Lower lockable cabinet internal dimensions | 400 x 500 x 520 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private manager office | Fits executive workspaces with lockable storage for confidential documents | |
|---|---|---|
| Home office study | Provides dedicated work surface and integrated storage for remote workers | |
| Small business workstation | Suitable for startup offices requiring budget commercial grade desks | |
| Conference side work surface | Functions as a supplementary table for meeting room materials and equipment | |
| Recommended chair pairing | Pairs with mid-back ergonomic office chairs with 520 mm adjustable seat height | |
| Recommended accessories | Works with monitor arms, desk lamps and under-desk cable trays |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional safety and performance requirements, applicable to clearance checks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, applicable to commercial office desk durability verification |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk top and pedestal quality checks | |
|---|---|---|
| GB/T 3327-2017 | Technical requirements for office desks, applicable to dimensional and stability verification | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to E0-grade core material verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk top and pedestal quality checks; 2. GB/T 3327-2017: Technical requirements for office desks, applicable to dimensional and stability verification; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to E0-grade core material verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
