| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled footprint | 1590 x 1590 x 1600 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Primary work surface depth | 600 mm | |
| Side return work surface depth | 450 mm | |
| Rear privacy screen height | 1200 mm | |
| Tabletop thickness | 19 mm | |
| Knee clearance width under primary desk | 800 mm | |
| Knee clearance height under desk | 690 mm | |
| Side storage unit height | 1100 mm | |
| CPU storage bay internal dimensions | 250 x 450 x 500 mm | |
| Cable grommet diameter | 60 mm | |
| Edge band thickness | 2 mm | |
| Support leg metal wall thickness | 1.2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 91 kg | |
|---|---|---|
| Drawer slide load rating | 25 kg | |
| Open shelf static load per level | 20 kg | |
| Net product weight | 91 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Adjustable foot height adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface and panels | 18mm E1 grade engineered wood with light oak/white thermally fused laminate | |
|---|---|---|
| Privacy screen lower section | 25mm fabric-wrapped acoustic fiberboard with sage green finish | |
| Privacy screen upper section | 3mm frosted acrylic louver panel with gray metal frame | |
| Structural support frame | 1.2mm thick powder-coated steel square tube legs and connectors | |
| Drawer and cabinet hardware | Zinc-plated steel full-extension ball-bearing slides with recessed ABS pulls | |
| Edge banding | 2mm thick impact-resistant PVC matching panel finishes |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | 60mm desktop grommet paired with under-desk cable raceway | |
|---|---|---|
| Integrated storage layout | Two open upper shelves, one utility drawer, one lower cabinet, dedicated CPU bay | |
| Adjustable leveling feet | Threaded height-adjustable feet at all base corners | |
| Modular connection compatibility | Pre-drilled panel connection points |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office individual workstations | Provides dedicated seated work space with privacy screen to reduce visual distraction | |
|---|---|---|
| Small business staff cubicle layouts | Integrates storage and cable management to minimize additional furniture requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural stability verification | |
|---|---|---|
| EN 527-2:2002 | Office work tables dimensional safety requirements, applicable to seated clearance verification | |
| EN 12521:2015 | Furniture strength, durability and safety for domestic and contract tables, applicable to load testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to desktop load, durability and stability testing for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable to drawer and shelf load rating and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel office desk construction and finish | |
|---|---|---|
| GB/T 10357.1-1989 | Furniture mechanical performance test for tables, applicable to desktop static and impact load verification | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to E1 grade engineered wood components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel office desk construction and finish; 2. GB/T 10357.1-1989: Furniture mechanical performance test for tables, applicable to desktop static and impact load verification; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to E1 grade engineered wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
