Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total static load capacity of worktop | 400 kg | |
|---|---|---|
| Total product weight (without pedestals) | 120 kg | |
| Recommended maximum user count | 4 | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | Melamine-faced particleboard | |
|---|---|---|
| Support frame | Powder-coated cold-rolled steel | |
| Desktop privacy dividers | Fabric-wrapped MDF core | |
| Mobile drawer fronts | Two-tone melamine particleboard | |
| Pedestal casters | Nylon swivel casters | |
| Drawer handles | Brushed aluminum alloy | |
| Center cable management column | Powder-coated steel | |
| Frame foot pads | Anti-slip rubber | |
| Pedestal lock | Zinc alloy keyed lock | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Per-seat cable routing | Pre-cut desktop grommets feed cables to central under-desk channel | |
|---|---|---|
| Mobile pedestal storage | Each pedestal has 2 stationery drawers and 1 hanging file drawer | |
| Desktop privacy separation | Raised dividers between opposite seats reduce visual distraction | |
| Frame leveling adjustment | Foot pads adjust up to 10 mm to stabilize desk on uneven floors | |
| Pedestal mobility | Locking casters allow pedestals to be repositioned or secured in place | |
| Central cable management | Vented central column conceals power strips and data cables | |
| Modular connection | Frame sections bolt together for on-site assembly | |
| Integrated task light mounting | Aluminum rail on top of dividers supports optional task lights | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan corporate offices | Four-seat layout supports dense team seating with privacy between users | |
|---|---|---|
| Startup and co-working spaces | Modular design allows flexible reconfiguration as team size changes | |
| Government and administrative work areas | Durable construction meets high-traffic daily use requirements | |
| Call center and back-office operations | Integrated cable management supports computer and phone equipment | |
| Training and temporary project spaces | Mobile pedestals allow quick workspace reorganization | |
| Small business open work areas | All-in-one configuration includes storage without extra furniture purchases |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for structural performance | |
|---|---|---|
| EN 1335-2:2009 | Office furniture stability requirements for free-standing workstations | |
| EN 14073-2:2004 | Office storage furniture safety requirements for mobile pedestals |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and drawer components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel support frame | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and drawer components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel support frame; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
