PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall cluster dimensions	2800 x 2400 x 750 mm
Per-user work surface dimensions	1400 x 600 mm
Work surface height	750 mm
Under-desk knee clearance height	670 mm
Knee clearance width per seat	580 mm
Central privacy panel dimensions	1200 x 300 mm
Work surface thickness	25 mm
PVC edge band thickness	2 mm
Side storage cabinet dimensions	1200 x 400 x 650 mm
Single drawer internal dimensions	300 x 350 x 150 mm
Storage cabinet door compartment dimensions	390 x 350 x 600 mm
Cable grommet diameter	60 mm
Square support leg section	45 mm
Storage cabinet base foot height	20 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Per-seat work surface static load capacity	113 kg
Total workstation net weight	290 kg
Recommended user capacity	4 users
Laminate surface abrasion resistance	2000 cycles
Leveling foot adjustment range	10 mm
Structural warranty	5 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles
Top Abrasion Reference	Acceptance target ≥4,000 abrasion cycles or finish-system test

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface	25mm melamine laminated particleboard with 2mm PVC edge banding
Support frame and legs	Powder-coated square steel tubing
Central privacy panels	Fabric-wrapped MDF core
Storage cabinet bodies	16mm melamine laminated particleboard with 6mm back panels
Hardware pulls	ABS plastic with matte orange finish
Cable management components	ABS plastic grommets and under-desk wire channels

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating layout	4-person face-to-face configuration with two seats per long side
Privacy screening	Low central desk-mounted dividers separate opposing workstations
Integrated storage	Fixed flanking side cabinets with 3 drawers and 1 door per end
Cable routing	Desktop grommets connect to under-desk wire management channels

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan corporate office areas	Ideal for team clusters in general administrative and staff work zones
Co-working and shared office spaces	Suitable for flexible team work areas requiring modular, expandable seating

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-1:2011	Office work tables, safety and strength requirements for commercial use
EN 527-2:2016	Office work tables, dimensional requirements for ergonomic seated use
EN 13722:2004	Office furniture, storage units strength and durability requirements

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products standard for safety, durability and structural performance
ANSI/BIFMA X5.9-2019	Storage units standard for office furniture performance requirements

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to panel construction
GB/T 3327-2017	Performance and test methods for office desks and workstations
GB 18584-2001	Limit of formaldehyde emission for indoor wooden furniture, required for indoor use

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction;
2. GB/T 3327-2017: Performance and test methods for office desks and workstations;
3. GB 18584-2001: Limit of formaldehyde emission for indoor wooden furniture, required for indoor use;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OW-4FT-2800

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OW-4FT-2800

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OW-4FT-2800Open Export Tool

Quick Actions

Post an RFQ

Product Description

This 4-person face-to-face modular office workstation offers a streamlined, organized solution for collaborative work environments, balancing open connectivity with individual user privacy. Designed in a balanced face-to-face seating layout, the cluster positions two workstations along each long side of the unit, separated by low, centrally mounted privacy dividers that sit between opposing seats to reduce visual distraction without blocking cross-team communication. Fixed side storage cabinets anchor both ends of the workstation, creating a defined, cohesive footprint that maintains clean sightlines across open floor plans, while matte orange hardware pulls add a subtle, polished design accent to the neutral-toned structure. The workstation is built for long-term commercial use, with a sturdy support structure of powder-coated square steel tubing fitted with adjustable leveling feet to accommodate uneven flooring. Each 25mm thick work surface is constructed from melamine laminated particleboard, finished with durable 2mm PVC edge banding to resist everyday wear from regular office use. Central privacy panels feature a fabric-wrapped MDF core to soften ambient visual noise, while integrated storage cabinets use 16mm melamine laminated particleboard with reinforced 6mm back panels. All hardware, including cable management grommets and under-desk wire channels, is made of durable ABS plastic. The unit delivers reliable load capacity for standard office equipment, with a 5-year structural warranty for core framework components. Practical, user-centric features support smooth daily operation: each work surface includes integrated cable grommets that feed directly into under-desk wire channels to contain power and data cords and reduce desktop clutter. The fixed flanking side cabinets offer three drawers and one enclosed door per end, giving each user close, accessible storage for personal items, documents, and office supplies without requiring additional mobile furniture. This workstation is ideally suited for open-plan corporate office zones, particularly team clusters for general administrative and regular staff work, as well as co-working and shared office spaces that benefit from modular, expandable seating arrangements. When planning procurement, note that each unit ships across multiple cartons, requires assembly on site, and pairs with standard office task chairs sized to fit the defined per-seat knee clearance. The modular design allows teams to expand cluster configurations as headcount grows, while the fixed storage elements reduce the need for separate ancillary storage furniture in high-density work areas.

FurnDim

4-Person Face-to-Face Modular Office Workstation with Central Dividers and Fixed Side Storage Specifications

OW-4FT-2800
