Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2920 x 1440 x 750 mm | |
|---|---|---|
| Privacy divider height above work surface | 450 mm | |
| Individual work surface per seat | 1200 x 600 mm | |
| Under-desk seated knee clearance height | 650 mm | |
| Under-desk storage pedestal dimensions | 400 x 400 x 600 mm | |
| Dedicated CPU bay compartment dimensions | 250 x 500 x 450 mm | |
| Work surface panel thickness | 50 mm | |
| Privacy divider panel thickness | 40 mm | |
| PVC edge banding thickness | 2 mm | |
| Metal support leg tube wall thickness | 1.5 mm | |
| Cable grommet opening diameter | 80 mm | |
| Integrated open storage shelf dimensions | 400 x 300 x 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 150 kg | |
|---|---|---|
| Drawer slide cycle durability | 50000 cycles | |
| Hinge cycle durability for cabinet doors | 80000 cycles | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Indicative product net weight | 180 kg | |
| Standard recommended user capacity | 4 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | E1 grade melamine-faced MDF/particleboard | |
|---|---|---|
| Privacy divider panels | Fabric-wrapped acoustic panel over aluminum frame | |
| Support leg framework | Powder-coated off-white steel splayed legs | |
| Storage pedestal cabinets | Matching melamine-faced engineered wood construction | |
| Drawer hardware | Zinc alloy lock cores with three-section ball bearing slides | |
| Edge sealing trim | 2mm thick impact-resistant PVC edge banding | |
| Desk leveler feet | Nylon-padded adjustable steel glides | |
| Cable management grommets | ABS plastic cable pass-through inserts | |
| Adjustable foot pads for pedestals | PP plastic height-adjustable support feet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Center privacy dividers | Fixed brown fabric dividers separate opposing seated work positions for visual privacy | |
|---|---|---|
| Per-seat storage pedestal | Fixed integrated unit with one lockable top drawer and one lower file drawer | |
| Dedicated CPU storage bays | Open compartments between pedestals sized to house full-size desktop computer towers | |
| Integrated cable management | Pre-cut grommets on dividers and work surface route power/data cables to under-desk trays | |
| Adjustable leg levelers | Rotating padded feet at each leg base correct uneven floors for stable work surface | |
| Lockable drawer security | Keyed lock on each pedestal top drawer secures personal office valuables and documents | |
| Modular expandable layout | Pre-drilled connecting hardware allows linking additional workstation clusters for larger teams | |
| Open top storage shelf | Recessed open shelf on each pedestal holds frequently used stationery and desk accessories | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff areas | Suitable for 4-person team clusters in corporate open office layouts to balance collaboration and privacy | |
|---|---|---|
| Call center and shared workspaces | Ideal for high-density seating with built-in cable management and personal storage for shift workers | |
| Startup and co-working spaces | Modular design allows flexible reconfiguration to match growing team size and layout changes | |
| Administrative department work areas | Integrated storage reduces need for separate cabinets, saving floor space in back-office zones | |
| Paired with ergonomic office task chairs | Designed to match standard 5-star base office chairs with 520 mm adjustable seat height | |
| Small business office fit-outs | All-in-one design reduces separate furniture purchases for budget-conscious office installations |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural performance verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and ergonomic requirements, applicable to clearance checks | |
| EN 1335-1:2020 | Office furniture ergonomic reference for matching workstation and chair dimensions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to pedestal drawer and cabinet testing | |
| ANSI/BIFMA G1-2013 | Ergonomic guidelines for office furniture, applicable to work height and clearance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and storage panel quality | |
|---|---|---|
| GB/T 3327-2016 | Performance standards for office desks and workstations, applicable to structural load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1 grade board selection | |
| GB/T 4897.3-2003 | Requirements for particleboard used in dry-condition furniture, applicable to substrate panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and storage panel quality; 2. GB/T 3327-2016: Performance standards for office desks and workstations, applicable to structural load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1 grade board selection; 4. GB/T 4897.3-2003: Requirements for particleboard used in dry-condition furniture, applicable to substrate panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
