Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| work surface thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| knee clearance height under work surface | 659 mm | |
| knee clearance width between leg and pedestal | 700 mm | |
| privacy divider dimensions | 1200 x 300 x 20 mm | |
| divider mounting bracket height | 30 mm | |
| attached storage pedestal dimensions | 450 x 600 x 620 mm | |
| cable grommet diameter | 54 mm | |
| splayed leg steel tube diameter | 50 mm | |
| pedestal floor leveler adjustment range | 10 mm | |
| top drawer internal dimensions | 380 x 500 x 80 mm | |
| lower cabinet internal height | 480 mm | |
| leg wall thickness | 1.5 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| total product net weight | 100 kg | |
|---|---|---|
| work surface static uniform load capacity | 122 kg | |
| drawer slide cycle durability | 50000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| recommended maximum user weight for seated use | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface | 25 mm particleboard core with thermally fused melamine laminate | |
|---|---|---|
| edge banding | 2 mm scratch-resistant PVC edge trim applied to all exposed top edges | |
| leg frame | 1.5 mm thick powder-coated white steel splayed angled legs | |
| leg accent brackets | Painted terracotta-finished steel support brackets at leg-desktop junction | |
| privacy divider panel | 20 mm thick MDF core with terracotta textured matte finish | |
| storage pedestal cabinet | 18 mm thick MFC (melamine-faced chipboard) with light off-white finish | |
| drawer hardware | Cold-rolled steel ball-bearing drawer slides with keyed cam lock | |
| cable grommets | ABS plastic round cable ports with brushed dark silver finish | |
| divider mounting brackets | Terracotta-finished cast aluminum clamp brackets | |
| floor levelers | Nylon base adjustable steel threaded glides under pedestal and legs | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| seated work surface | Fixed 750 mm height aligned to standard ergonomic seated office use | |
|---|---|---|
| privacy screening | Low 300 mm high rear divider blocks direct sightlines at desk level | |
| locking storage | Keyed lock secures top drawer and lower cabinet compartment | |
| cable management | Dual 54 mm grommets route power and data cables from work surface to floor | |
| floor leveling | Adjustable glides under pedestal and legs correct up to 10 mm of floor unevenness | |
| drawer operation | Full-extension ball-bearing slides allow complete access to drawer contents | |
| modular compatibility | Desk can be grouped side-by-side to form multi-desk open-plan workstation rows | |
| surface maintenance | Stain-resistant melamine surface wipes clean with standard office cleaning products | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open-plan office work zones | Suitable for open-office layouts with low divider providing individual privacy | |
|---|---|---|
| private staff home offices | Compact single-user footprint fits residential work spaces for remote work | |
| co-working shared workspaces | Fixed modular design supports flexible hot-desking arrangements for daily users | |
| small business administrative offices | Integrated lockable storage secures personal documents and office supplies | |
| startup office fit-outs | Contemporary terracotta accent color complements modern neutral office interiors | |
| design studio workstations | Smooth wide work surface supports drawing tablets, laptops and reference materials |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables: safety and strength requirements, applicable to structural stability | |
|---|---|---|
| EN 527-2:2016 | Office worktables: dimensional requirements for seated work, applicable to ergonomic clearance | |
| EN 14073-2:2004 | Office storage furniture: safety requirements for pedestal cabinets | |
| EN 12721:2000 | Furniture: assessment of surface resistance to dry heat, applicable to laminate tops |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products: safety and performance standard for structural load and durability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units: performance requirements for pedestal drawers and locks | |
| ANSI/BIFMA X5.1-2017 | Office Chairs: reference for seating compatibility with standard desk height |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk and pedestal construction | |
|---|---|---|
| GB/T 3327-2020 | Performance test methods for office desks, applicable to load and stability testing | |
| GB 18584-2001 | Limit of formaldehyde emission for interior decoration wooden furniture, required for indoor air quality | |
| GB/T 4897-2015 | Particleboard specification, applicable to work surface core material requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk and pedestal construction; 2. GB/T 3327-2020: Performance test methods for office desks, applicable to load and stability testing; 3. GB 18584-2001: Limit of formaldehyde emission for interior decoration wooden furniture, required for indoor air quality; 4. GB/T 4897-2015: Particleboard specification, applicable to work surface core material requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
