| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| desktop thickness | 25 mm | |
| edge banding thickness | 2 mm | |
| modesty panel thickness | 18 mm | |
| modesty panel height | 235 mm | |
| seated knee clearance height | 680 mm | |
| knee clearance width | 1100 mm | |
| desktop cable grommet diameter | 60 mm | |
| left under-desk pedestal width | 400 mm | |
| leg frame tube wall thickness | 1.5 mm | |
| adjustable foot height adjustment range | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| desktop uniform static load capacity | 160 kg | |
|---|---|---|
| product net weight | 52 kg | |
| recommended maximum user weight for seated use | 130 kg | |
| melamine surface heat resistance | 120 °C | |
| melamine surface abrasion resistance | 2000 cycles | |
| standard limited warranty period | 10 years | |
| available color finish options | 3 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | 25mm E0-grade engineered particleboard | |
|---|---|---|
| desktop surface | Heat-resistant melamine laminate | |
| support frame | 1.5mm thick powder-coated steel tube | |
| rear modesty panel | 18mm perforated powder-coated steel | |
| desktop edging | 2mm thick impact-resistant PVC edge banding | |
| under-desk pedestal body | 18mm melamine-faced engineered wood | |
| leveling feet | Reinforced nylon with threaded steel insert | |
| cable grommets | ABS plastic with brushed metal finish cover | |
| right leg power port housing | Fire-resistant ABS plastic | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| cable management system | Dual desktop grommets + perforated panel cutouts + under-desk routing channel | |
|---|---|---|
| floor leveling adjustment | Threaded adjustable feet on each leg base | |
| under-desk storage pedestal | Partial left-side enclosed compartment with sliding access | |
| integrated right-leg power access | Recessed port cutout on right leg frame | |
| ventilated modesty panel | Perforated full-width rear panel | |
| seated work ergonomics | Fixed 750mm work surface height | |
| frame structural bracing | Continuous curved cantilever leg connection to modesty panel | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| home office workspace | Fits standard home study rooms for remote work and personal computing use | |
|---|---|---|
| open plan office workstation | Suitable for commercial open office layouts for individual staff seating | |
| small business reception workspace | Works for reception desk use in compact office entry areas | |
| student study desk | Appropriate for dormitory or bedroom study and homework use | |
| gaming desk setup | Supports monitor, PC and peripheral placement for recreational PC gaming | |
| minimum required installation space | 2000 x 1000 mm clear floor area to accommodate chair and access |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional performance requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety and strength test methods | |
| EN 13986:2004 | Wood-based panel performance requirements for furniture construction |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for office applications |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Desk, chair and bench dimensional tolerance requirements for office furniture | |
|---|---|---|
| GB/T 3327-2016 | Mechanical performance test methods for office desk furniture | |
| GB 18580-2017 | Formaldehyde emission limits for engineered wood used in furniture | |
| GB/T 4897.3-2015 | Particleboard performance requirements for furniture grade substrates |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Desk, chair and bench dimensional tolerance requirements for office furniture; 2. GB/T 3327-2016: Mechanical performance test methods for office desk furniture; 3. GB 18580-2017: Formaldehyde emission limits for engineered wood used in furniture; 4. GB/T 4897.3-2015: Particleboard performance requirements for furniture grade substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
